NetCloud Service for Small Branch with the E100 Series Enterprise Router provides reliable LTE, secure connections to the Internet or VPN support, LAN switching, and Wi-Fi 5 to enable comprehensive, all-in-one office network. Maintain the organizational security and compliance profile through stateful, zone-based and application-aware firewall, unified threat management, and Wi-Fi security. Leverage GPS capabilities to locate the position of the equipment and enhance asset tracking detail. The portable router designed for U.S. and Canada makes it easy to establish a secure, dedicated connection to the headquarters or the Internet to access crucial business applications.
Routers
Cradlepoint E100-C7C – wireless router – WWAN – Wi-Fi 5 – Wi-Fi 5 – 3G, 4G – desktop, wall-mountable, ceiling-mountable
Tech overview
Cradlepoint E100-C7C – Wireless router – WWAN – 4-port switch – GigE – Wi-Fi 5 – Dual Band – 3G, 4G – wall-mountable, ceiling-mountable – with 1 year NetCloud Small Branch Essentials Plan
AED3,199.00
General
| Attribute | Details |
|---|---|
| Device Type | Wireless router – 4-port switch (integrated) |
| Bundled Services | 1 year NetCloud Small Branch Essentials Plan |
| Enclosure Type | Desktop, wall-mountable, ceiling-mountable |
| Connectivity Technology | Wireless, wired |
Data Link Protocol
| Attribute | Details |
|---|---|
| Data Link Protocol | Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Frequency Band
| Attribute | Details |
|---|---|
| Frequency Band | 2.4 GHz / 5 GHz |
Performance
| Attribute | Details |
|---|---|
| Stateful firewall throughput | 850 Mbps |
| IPS throughput | 250 Mbps |
| VPN throughput (IPSec) | 40 Mbps |
| Maximum throughput (2.4 GHz) | 300 Mbps |
| Maximum throughput (5 GHz) | 867 Mbps |
Capacity
| Attribute | Details |
|---|---|
| Concurrent VPN tunnels | 20 |
| Concurrent TCP sessions | 32000 |
| Typical client count | 5 |
Features
| Attribute | Details |
|---|---|
| Features | VPN support, DFS support, Intrusion Prevention System (IPS), security lock slot (cable lock sold separately), 2×2 MU-MIMO technology, security slot (Kensington security lock compatible), Zero-Touch Deployment, SecureBoot |
Compliant Standards
| Attribute | Details |
|---|---|
| Compliant Standards | Wi-Fi CERTIFIED, UL, cUL, RoHS, EN 60950-1, PTCRB, CP65, EN 62368-1, FCC Part 96, CB Scheme |
Built-in Devices
| Attribute | Details |
|---|---|
| Built-in Devices | GNSS receiver |
Status Indicators
| Attribute | Details |
|---|---|
| Status Indicators | Power, signal strength, 4G, link/activity/speed, Wi-Fi |
Line Properties
| Attribute | Details |
|---|---|
| Line Coding Format | 64 QAM |
Communications
| Attribute | Details |
|---|---|
| Type | Wireless cellular modem |
| Cellular Protocol | UMTS, WCDMA, HSPA+, LTE |
| Generation | 3G, 4G |
| Cellular Band | LTE B13, LTE B2, LTE B4, LTE B12, LTE B7, LTE B25, LTE B26, LTE B5, LTE B66, LTE B41, LTE B14, LTE B42, LTE B43, LTE B48, LTE B71, WCDMA B2, WCDMA B5, WCDMA B4 |
| Max Transfer Rate | 300 Mbps |
Expansion / Connectivity
| Attribute | Details |
|---|---|
| Interfaces | LAN: 4 x 10Base-T/100Base-TX/1000Base-T (PoE++) – RJ-45 <br> WAN: 1 x 10Base-T/100Base-TX/1000Base-T <br> USB 2.0: 1 x 4 pin USB Type A <br> Antenna: 3 x SMA |
| Expansion Slots | 2 (total) / 2 (free) x Mini-SIM |
| Antenna | External detachable and internal |
Power
| Attribute | Details |
|---|---|
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V |
Miscellaneous
| Attribute | Details |
|---|---|
| Included Accessories | 4 rubber feet, 2 x cellular antennas, 2 x SIM door screw |
| Cables Included | 1 x network cable – 5 ft |
| Localization | North America (US and Canada) |
Dimensions & Weight
| Attribute | Details |
|---|---|
| Width | 10.6 in |
| Depth | 5.3 in |
| Height | 1.9 in |
| Weight | 23.98 oz |
