Cradlepoint R920 – wireless router – WWAN – Wi-Fi 6, Wi-Fi 6 – 3G, 4G – desktop

Add to Wishlist

Tech overview

Cradlepoint R920 – Wireless router – WWAN – GigE – Wi-Fi 6 – Dual Band – 3G, 4G – with 5 years NetCloud Mobile Essentials Plan

AED7,299.00

Add to Wishlist

The R920 Series, a versatile LTE router with a wide span of use cases, provides flexible connectivity in vehicles and IoT deployments. With its IP64 ruggedization rating and certifications for public safety networks, the R920 can be deployed in automobile trunks, warehouses, NEMA enclosures, and harsh environments. The R920 supports a managed accessory that allows the addition of a 5G modular modem for increased performance and multiple carrier support. The ruggedized design and the CBRS band support make it ideal for private networks. The solution is highly extensible with APIs, SDKs, and integrations into IoT platforms, and the generous memory supports onboard edge containers and security services.

SKU: MA05-0920-C7A-NA Category: Tag:
Specifications Details
General
Device Type Wireless router
Bundled Services 5 years NetCloud Mobile Essentials Plan
Enclosure Type Desktop
Connectivity Technology Wireless, wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Frequency Band 2.4 GHz / 5 GHz
Performance Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1.2 Gbps ¦ Stateful firewall throughput: 940 Mbps ¦ IPS throughput: 940 Mbps ¦ VPN throughput (IPSec): 100 Mbps ¦ LTE downlink bandwidth: 300 Mbps ¦ LTE uplink bandwidth: 150 Mbps
Capacity Concurrent VPN tunnels: 20 ¦ Concurrent TCP sessions: 130000 ¦ Typical client count: 30
Encryption Algorithm WPA2-Enterprise, WPA3-Enterprise, WPA3-Personal, WPA2-Personal, WPA-Personal
Features DFS support, Access Point operational mode, Wireless Client Mode, SMS remote control, 2×2 MIMO technology, 3GPP Release 11, Ignition Sense, Docker Support, dual core CPU, GPS/GLONASS/Galileo/BeiDou/QZSS support
Compliant Standards Wi-Fi CERTIFIED, IEEE 802.11k, IEEE 802.11v, UL, cUL, IC, FCC, RoHS, IP64, WEEE, E Mark, PTCRB, RoHS2, MIL-STD 810G 514.6, CP65, SAE J1455, EN 62368-1, IEC/EN 61373 Category 1 Class B, C1D2, CB Scheme
Flash Memory 8 GB
Built-in Devices GNSS receiver
Line Properties Line Coding Format: 64 QAM
Communications
Type Wireless cellular modem
Cellular Protocol UMTS, WCDMA, HSPA+, FDD LTE, TDD LTE
Generation 3G, 4G
Cellular Band LTE B13, LTE B2, LTE B4, LTE B12, LTE B7, LTE B25, LTE B26, LTE B5, LTE B66, LTE B41, LTE B14, LTE B42, LTE B43, LTE B48, LTE B71, HSPA+ B2, HSPA+ B4, HSPA+ B5
Max Transfer Rate 300 Mbps
Internet of Things (IoT)
Internet of Things (IoT) Compatible Yes
Communications Technology Bluetooth Low Energy (LE), LTE Cat 7
Expansion / Connectivity
Interfaces WAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A ¦ Antenna: 2 x RP-SMA – Wi-Fi ¦ Antenna: 1 x RP-SMA – Bluetooth ¦ 1 x GPIO – 2 pin ¦ Antenna: 1 x SMA – GNSS antenna ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ Antenna: 2 x RP-SMA – LTE
Expansion Slots 2 (total) / 2 (free) x Nano-SIM
Antenna External detachable
Power
Power Device External power adapter (not included)
Power Consumption Operational 14.5 Watt
Miscellaneous
Included Accessories Mounting template
Cables Included 1 x GPIO cable – 10 ft
MTBF 388,022 hour(s)
Localization North America (US and Canada)
Dimensions & Weight
Width 5.3 in
Depth 4.8 in
Height 1.6 in
Weight 20.99 oz
