The CyberPower PDU15B12R, a 12-outlet (rear) rackmount basic power distribution unit (PDU), provides 100 – 125 V 15A output. It distributes power to 12 NEMA 5-15R receptacles from a single NEMA 5-15P input with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications, the PDU15B12R has rugged, industrial-grade metal housing and a 15-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray, and is ETL/RoHS certified. A limited lifetime warranty covers defects in materials and workmanship in the product under normal use and conditions.Ā Power Distribution
Delivers AC power to servers, equipment, and connected devices via a power distribution unit.
Power distribution unit
CyberPower 15A Basic PDU 1U 12 Out 5-15R 120V 12R Out 5-15P 15FT Cord
- Basic PDU
- 12 NEMA 5-15R output receptacles (12 Rear)
- 120V AC – 50/60Hz – 15-amp electrical capacity with circuit breaker
- 1U Rack Mount – Rugged industrial-grade metal housing
AED1,099.00
Category | Attribute | Details |
---|
General Information | Product Name | 15A Basic PDU 1U 12 Out 5-15R 120V 12R Out 5-15P 15FT Cord |
Product Series | Basic PDU |
Product Model | PDU15B12R |
Product Type | PDU |
Technical Information | PDU Type | Basic |
Phase | Single Phase |
Plug / Connector Type | NEMA 5-15P |
Receptacle Type | NEMA 5-15R |
Receptacle Detail | 12 x NEMA 5-15R |
Protection Type | Overload Protection |
Power Description | Input Voltage | 120 V AC |
Input Voltage Range | 100 V AC – 125 V AC |
Output Voltage Range | 100 V AC – 125 V AC |
Physical Characteristics | Mounting Orientation | Vertical |
Mount Type | Rack-mountable |
Rack Height | 1U |
Height | 1.8″ |
Width | 17.5″ |
Length | 1.5″ |
Miscellaneous | Package Contents | Basic PDU15B12R 12-Outlets PDU Cord Retention Tray User Manual Screw Kit Cord Clip Kit Horizontal Mounting Brackets Vertical Mounting Brackets Product Registration Card |
Energy Star | No |
Environmentally Friendly | Yes |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Other Information | Product Family | Basic PDU |
