CyberPower Switched ATS PDU44001 – power distribution unit


Quick tech specs

  • Power distribution unit (rack-mountable)
  • 1-phase
  • input: 2 x NEMA 5-15P
  • 1U
  • black
  • AC 100-120 V
  • serial, Ethernet, USB
  • output connectors: 10 (10 x NEMA 5-15R)
  • 10 ft cord

AED4,699.00

Know your gear

The CyberPower PDU44001 Switched ATS PDU ensures the continued operation of important devices. This unit provides power redundancy to single-corded connected equipment and is ideal for data centers and network closets. If the primary power source’s power exceeds or fails to meet the lower or upper criteria, the PDU will switch to the secondary power source to ensure uninterrupted functioning. When the incoming power becomes stable, the PDU will switch back to the primary power source. This unit also includes real-time remote and local monitoring, as well as outlet management.

The PDU44001 accepts 100 volts to 120-volt inputs and features ten NEMA 5-15R outlets. Separate power sources (A and B) are connected with dual NEMA 5-15P power cords and information about each power source is prominently displayed on the front panel.

SKU: PDU44001 Category: Tag:
Category Specification
Overview
Brand CyberPower
Product Line CyberPower Switched ATS
Model PDU44001
Manufacturer Cyber Power
Network & Communication
Remote Management DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, SMTP, SNMP 1, SNMP 3, SSH, Telnet, TFTP
Remote Management Interface Ethernet, Serial, USB
Connectivity
Interface Provided – 1 x cascading – RJ-45 – 1 x management (Ethernet) – RJ-45 – 1 x sensor – RJ-45 – 1 x serial – RJ-45 – 1 x USB – 4 pin USB Type A
Power
Emergency Power Off Automatic Transfer Switch (ATS), Built-in maintenance bypass, Firmware upgradable, LCD display
Frequency 50/60 Hz
Input Connector Type 2 x power NEMA 5-15P
Input Wiring 1-phase
Max Input Current 15 A
Output Connector Quantity 10
Output Connector Type 10 x power NEMA 5-15R
Power Output Connectors 10 x power NEMA 5-15R
Provided Voltage AC 100–120 V
Required Voltage AC 100–120 V
Switching Capacity 10 milliseconds
Software
Software Type PowerPanel Business
Technical Information
Form Factor (Power Device) Rack-mountable
Max Operating Temperature 113°F
Min Operating Temperature 32°F
Operating Humidity 0–95% (non-condensing)
Product Information
Cord Length 10 ft
Features Metal housing
Packaged Quantity 1
Product Type Power distribution unit
Subcategory Power distribution devices
Included Items
Cables Power cable – 10 ft
Included Accessories Cord retention tray
Dimensions & Weight
Height 1.8 inch
Height (Rack Units) 1 U
Weight 10.01 lbs
Width 17.1 inch
Depth 8.4 inch
Physical Characteristics
Color Black
Color Category Black
