Dell 403-BBTM / 8524M 2TB NVMe PCIe Mixed Use Express Flash HHHL AIC, P4600 – Brand New
Dell 403-BBTM / 8524M 2TB / 2000GB NVMe / NVM Express / NVMe / Non-Volatile Memory Express PCIe / PCI Express / Peripheral Component Interconnect Express MU / Mixed Use Express Flash HHHL / Half Height Half Length AIC / Add-In-Card, P4600 – Brand New
Dell PowerEdge Express Flash NVMe āMixed Useā PCIe SSD.
The Dell PowerEdge Express Flash NVMe Mixed Use PCIe SSD is based on the IntelĀ® P4600 product family. Engineered for mixed use workloads, this PowerEdge Express Flash device provides outstanding performance and medium endurance with Three Drive Writes per Day (3 DWPD) and utilizing 3D TLC NAND.
This Mixed Use class PCIe solid-state storage device is designed for solutions requiring high read & write IOPs, ultra-low latency and enterprise-class storage reliability and serviceability. The Express Flash NVMe PCIe-SSD is ideal for demanding mixed use enterprise environments, such as E-Commerce, Seismic Analysis and OLTP Database workloads. Built with server-grade, 3D TLC NAND, the low-latency PowerEdge Express Flash NVMe PCIe SSD can provide unmatched throughput.
The Express Flash NVMe device is designed to optimize the high-performance NAND, achieving ultrahigh IOPs and sequential read/write throughput performance.
Breakthrough Performance
The Dell PowerEdge Express Flash NVMe āMixed Useā PCIe SSD enables IOPS performance that far surpasses conventional rotating hard drives. The Express Flash device is designed to deliver sequential throughput on reads and writes of up to 3.3/2.2 GB/s respectively.
Storage Management
Dell storage management applications enable you to manage and configure the Express Flash PCIe SSD subsystem, control and monitor multiple PCIe SSD devices, and provide online maintenance. These Express Flash Mixed Use devices, based on the Intel P4600 family, are fully integrated with the 14th generation PowerEdge server management tools.1Ā The Express Flash NVMe PCIe SSD solution supports the unified extensible firmware interface (UEFI) and human interface infrastructure (HII), Integrated Remote Access Controller (iDRAC) with Lifecycle Controller and the Dell OpenManageā¢ Server Administrator (OMSA) application. UEFI and HII support the pre-operating system management, iDRAC delivers agent-free local and remote management and OMSA provides operating system management.
Durability
Enterprise-grade 3D TLC NAND and sophisticated NAND-management algorithms delivers 3 DWPD with 11.49PB & 22.98PB and 14.25PB & 29.21PB of Petabytes Written (PBW) drive life for the 1.6TB & 3.2TB ā 2.5ā PCIe-SSDs and the 2TB & 4TB HalfHeight, Half-Length Add-In-Card (AIC) devices respectively. Since NAND SSDs have a finite number of program and erase cycles, Dell warrants the Express Flash PCIe SSD to a maximum amount of data written to the SSD in PBW. The SSD monitors these cycles, and Dell software management applications notify you when the warranty limits are reached.2
Hot-Swap
Dell PowerEdge Express Flash PCIe SSDs support orderly hot swap, allowing you to add or remove a device without halting or rebooting the system in which the devices are installed. Dell supported PCIe SSD hotswappable functions3 include:
- Orderly or Hot Insertion
- Orderly Removal
- Orderly Swap
Device Monitoring
The self-monitoring analysis and reporting technology (SMART) feature set minimizes unscheduled system downtimes by providing a method of early detection of device degradation or fault. By monitoring and storing critical performance and calibration parameters, the SMART feature-set attempts to predict degradation or fault conditions. The knowledge of a negative reliability condition allows the host system to warn you of an impending risk of device failure and advise on the appropriate action.
Intel P4600 lacks full integration with previous generation Dell EMC servers. Device management is handled via Intel Device management tools.
Hot swap features only supported on 2.5ā PCIe SSD
Manufacturer Part# : 8524M, 08524M
Dell Part# : 403-BBTM
This product is compatible with the following systems:
PowerEdge C4140, C6420, FC430, FC640, M640 VRTX, R440, R540, R630, R640, R6415, R730, R740, R740XD, R7415, R7425, R840, R940, R940xa, T640
| Weight | 1.133 kg |
|---|
| Express Flash NVMe āMixed Useā PCIe SSD & PCIe SSC specification | |
|---|---|
| Dell Model # | 403-BBTM |
| Manufacturer Model # | 8524M 08524M |
| Capacity | HHHL AIC
2.5ā U.2
|
| Interface | PCIe Gen3 x4 |
| Sequential Read/Write | HHHL AIC
2.5ā U.2
|
| Random Read/Writes | HHHL AIC
2.5ā U.2
|
| Latency | Read 90usā“ ā Write 30usā“ |
| Active Power Consumption | 25W Maximum |
| Supported Operating Systems | MicrosoftĀ® Windows ServerĀ® 2016
Red HatĀ® Enterprise LinuxĀ® 7.3 or later
*See Userās Guide for most up to date OS support. |
| Form Factor & Dimensions | 2.5 inch
HHHL (Half Height, Half Length) add-in card
|
Ā¹ Unformatted; 1GB = 1 billion bytes; formatted capacity is less
Ā² 128KB transfer size, steady state
Ā³ 4KB transfer size, steady state, QD=256
ā“ 4KB transfer size, steady state, QD=1
Read latency captured under sustained Random workload
Write latency captured under sustained Sequential Workload.
