Dell 6R5R8 / SanDisk Lightning Mixed Use LB206M 200GB SLC 6Gbps SFF Enterprise SAS SSD


Capacity:Ā 200GB

Speed:Ā Solid State Memory

Interface Types:Ā SAS Serial Attached SCSI

Form Factor:Ā 2.5inx15mm SFF Server Drive

Sector Size:Ā 512 / 512e

Sustained Throughput:Ā 320

Electrical Interface:Ā SAS-2 Serial Attached SCSI v2 – 6.0Gbps

SSD Type:Ā SLC

SSD Endurance DWPD:Ā Enterprise Mixed UseLB206M

AED599.00

Dell 6R5R8 / SanDisk Lightning Mixed Use LB206M 200GB SLC 6Gbps SFF Enterprise SAS SSD – Refurbished OEM

Dell 6R5R8 / SanDisk Lightning Mixed Use LB206M 200GB SLC 6Gbps SFF Enterprise SAS SSD

Alternate Part Numbers:Ā 6R5R8 06R5R8

LightningĀ® Mixed-Use
6Gb/s SAS Enterprise Solid State Drives
The challenges for predictable performance and increased storage capacity are ever present in today’s data centers. Managers are tasked to satisfy demand without new IT capital investment or the cost of increasing floor space. Enterprise SSDs provide substantial performance and footprint benefits over traditional HDDs. This enables IT service providers to replace hundreds of HDDs with a single SSD creating a more efficient and reliable network while reducing capital expenditures, space and energy consumption. Lightning SSDs rank among the most competitive solutions in the industry, offering unmatched speed with a history of successful implementations into existing IT infrastructures.

Since not all data centers are created equal, the key to achieving increased data and system performance is in understanding the specific application workload. Lightning Mixed-Use 6Gb/s (SAS) SSDs offer solid I/O cost-to-performance benefits where quick access to data is vital. Available in 200GB, 400GB and 800GB capacities, Lightning Mixed-Use SSDs provide an I/O pattern designed predominately for application workloads such asĀ On-line Transaction Processing (OLTP) Databases, Infrastructure, E-mail/Messaging, Virtual Desktop, and Collaboration, with a typical workload comprised of a 70/30 read/write mix.

Lightning SSDs deliver the industry’s leading I/O sustained performance with the most predictable performance profile across a wide range of workloads. Lightning Mixed-Use SSDs are designed with an advanced innovative controller that uses a parallel processing architecture to deliver proven and tested superior reliability for storage and server environments. Lightning SSDs have been specifically designed for demanding, mission-critical, 24/7 applications.


Compatibility:

This drive is compatible with any server that accepts small form factor (SFF) SAS hard drives

Lightning Mixed-Use 6Gb/s SAS Enterprise SSDs – Product Specifications
Interface, Capacity, and Memory Technology LB 206M LB 406M LB 806M
Host Interface 6Gb/s SAS
Interface Ports Dual (2) full-duplex
Form Factor 2.5 inch
User Capacities 200GB 400GB 800GB
Sector Sizes Supported 512, 520, or 528 bytes/sector
Reliability
Unrecovered Bit Error Rate (UBER) <1 sector in 1017 bits read
End-to-End Data Protection No performance impact
Patrol Read (automatic) No performance impact
Power-on Hours 8760 hours per year
MTBF 2 million hours
Warranty Lesser of 5 years or maximum endurance used
Physical Dimensions
Height (max) 15.0 mm
Width (max) 70.1 mm
Length (max) 100.45 mm
Weight 0.238 Kg
Power Consumption
Idle 3.9 watts
Typical 5.9 watts
Environment
Operating Temperature (ambient) 0 to 60° C
Non-operating Temperature -40 to 85° C
Start-up time (Power-On to Ready) <15 seconds




ROHS Compliant

Alternate MPNs:Ā 6R5R8 06R5R8

Weight:Ā 1Ā lb
