Dell 8038H / Toshiba PM5-M Series KPM5XMUG3T20 3.2TB 12Gbps WI SAS SFF SSD
Capacity: 3.2TB
Speed: Solid State Memory
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 2100/2100
Electrical Interface: SAS-3 Serial Attached SCSI v3 – 12.0Gbps
SSD Type: TLC
SSD Endurance DWPD: Enterprise Write Intensive
Voltage: 12V
Compatible Systems: Dell 13th Gen. MD3x60 High Density Arrays, Dell MD3060 MD3260 MD3660
AED10,999.00
Dell 8038H / Toshiba PM5-M Series KPM5XMUG3T20 3.2TB 12Gbps WI SAS SFF SSD – Brand New
Dell 8038H / Toshiba PM5-M Series KPM5XMUG3T20 3.2TB 12Gbps Write Intensive 10-DWPD TLC 2.5″ SFF SAS / Serial Attached SCSI Enterprise Solid State Drive – Brand New
Alt PNs: 8038H / 08038H / KPM51MUG3T20
PM5-M 12.0 Gbit/s SAS SSD is optimized for write-intensive applications, including online transaction processing (OLTP) and e-commerce. The Series is designed to deliver high levels of performance, quality and reliability for mission-critical, hyperscale and virtualized environments.
Featuring KIOXIA Corporation’s 64-layer BiCS FLASH™ 3D memory, this 5th generation enterprise SAS SSD PM5-M Series offers 10 DWPD (Drive Writes Per Day) with capacities up to 3.2 TB.
Key Features
- 12.0 Gbit/s SAS interface with single/dual port and MultiLink SAS™ support
- Capacities from 400 GB to 3.2 TB
- T10 Multi-Stream Write support
- Up to 385 K random read IOPS (4 KiB) in dual port mode
- 2.5 inch form factor, 15 mm Z-height
- 10 DWPD with 100 % Random Write Workload
- Power loss protection and end-to-end data protection, including T10 DIF
- Pin-3 power disable support
- Sanitize Instant Erase (SIE) option
- Self-Encrypting (SED) option
- Self-Encrypting (SED), FIPS 140-2 validated option
- 5-year limited warranty
Key Applications
- Mission-Critical Enterprise Workloads
- Hyperscale and Virtualized Environments
- General online transaction processing (OLTP)
- E-commerce
Compatibility:
This drive is compatible with any server that accepts 2.5in x 15mm (SFF) SAS drives.
| Enterprise Mid Endurance SSD | |
|---|---|
| Model Number | KPM5XMUG3T20 |
| Basic Specifications | |
| Interface | SAS-3.0 |
| Interface Speed | 12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Memory Type | BiCS FLASH TLC |
| Formatted Capacity | 3.2TB / 3,200GB |
| Sustained 64Kib Sequential Read | 2,100 MiB/s |
| Sustained 64Kib Sequential Write | 2,10 MiB/s |
| Sustained 4KiB Random Read (Up to) | 370,000 IOPS |
| Sustained 4KiB Random Write (Up to) | 230,000 IOPS |
| Reliability | |
| MTTF | 2,500,000 hours |
| DWPD | 10 |
| Power Requirements | |
| Supply Voltage | 5 V + 10% / – 7 % 12 V ± 10 % |
| Power Consumption (Ready) | 5.0 W Typ. |
| Dimensions | |
| Height | 15.0 mm +0 , -0.5 mm |
| Width | 69.85 ± 0.25 mm |
| Length | 100.45 mm Max |
| Weight | 130 g Max |
| Environmental Specifications | |
| Temperature (Operating) | 0 to 30 °C |
| Relative Humidity ( Operating ) | 5 to 95 % R.H. (No condensation) |
| Vibration ( Operating ) | 21.27 m/s2 { 2.17 Grms } ( 5 to 800 Hz ) |
| Shock ( Operating ) | 9,800 m/s2 { 1,000 G } ( 0.5 ms duration ) |
ROHS Compliant
Alternate MPNs: 8038H 08038H KPM51MUG3T20
Weight: 0.7 lb
