| Category | Specification |
|---|
| General Information |
| Product Name | Basic ePDU 1U with Fil BKR C20 Input 12 C13 Outlets |
| Product Line | ePDU |
| Product Series | T992 |
| Product Model | T9092B-CBSF |
| Product Type | PDU |
| Technical Information |
| Plug / Connector Type | IEC 60320 C20 |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 12 x IEC 60320 C13 |
| Protection Type | Surge Protection, Spike Protection |
| Power Description |
| Input Voltage | 120 V AC, 230 V AC |
| Input Voltage Range | 125 V AC – 240 V AC |
| Output Voltage | 240 V AC |
| Power Rating (Watt) | 3330 W |
| Physical Characteristics |
| Mounting Orientation | Horizontal |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7″ |
| Width | 19″ |
| Depth | 5″ |
| Miscellaneous |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
