| Category | Field | Value |
|---|
| General Information | Product Name | Epdu 1U Mi L6-30P Input 12X6-15R Outlets |
| Product Line | ePDU |
| Product Series | T982 |
| Product Model | T982F1-F-SL-109 |
| Product Type | PDU |
| Technical Information | Plug / Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA 6-15R |
| Receptacle Detail | 12 x NEMA 6-15R |
| Protection Type | Surge Protection, Spike Protection |
| Interfaces / Ports | Network (RJ-45) | Yes |
| Power Description | Input Voltage | 230 V AC |
| Output Voltage | 240 V AC |
| Power Rating (VA) | 5760 VA |
| Physical Characteristics | Mounting Orientation | Horizontal |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7″ / 43.18 mm |
| Width | 19″ / 482.6 mm |
| Depth | 7″ / 177.8 mm |
| Other Information | Product Family | ePDU T982 |
