Power distribution unit
Eaton Epdu 2U L21-20P 18 C13 3 C19 Mi
- Versatile outlet mix – balances C13/C19 needs
- Secure input – L21-20P twist-lock connector
- Moderate capacity – 20A/208V operation
AED6,399.00
2U EPDU with L21-20P input and 18xC13/3xC19 outlets for medium-density racks.
| Category | Specification |
|---|
| General Information |
| Product Name | Eaton ePDU 2U L21-20P 18 C13 3 C19 Mi |
| Manufacturer Part Number | PC3753-20 |
| Product Line | ePDU |
| Product Type | PDU |
| Technical Information |
| Plug / Connector Type | NEMA L21-20P |
| Receptacle Type | IEC 60320 C13, IEC 60320 C19 |
| Receptacle Detail | 18 x IEC 60320 C13 3 x IEC 60320 C19 |
| Interfaces/Ports |
| Network (RJ-45) | Yes |
| Power Description |
| Input Voltage | 120 V AC, 230 V AC |
| Input Voltage Range | 120 V AC – 208 V AC |
| Output Voltage | 240 V AC |
| Power Rating (VA) | 5760 VA |
| Physical Characteristics |
| Mount Type | Rack-mountable |
| Rack Height | 2U |
| Height | 3.4″ |
| Width | 19″ |
| Depth | 9.5″ |
| Miscellaneous |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Other Information |
| Product Family | ePDU |
