Power distribution unit
EATON Epdu Ba 1u Mil 6X5-15R 2X5-20R
- Rugged Design – built for harsh environments and military applications
- High Reliability – ensures consistent power delivery in demanding conditions
- Compact Form Factor – fits into a 1U rack space
AED24,599.00
The Eaton ePDU BA 1U MIL 6X5-15R 2X5-20R is a military-grade power distribution unit designed for rugged environments, providing reliable power supply to critical equipment.
General Information
| Field | Details |
|---|---|
| Product Name | Epdu Ba 1U Mil 6X5-15R 2X5-20R |
| Manufacturer Part Number | TPC2806 |
| Product Line | ePDU |
| Product Type | PDU |
Technical Information
| Field | Details |
|---|---|
| Receptacle Type | NEMA 5-15R, NEMA 5-20R |
| Receptacle Detail | 6 x NEMA 5-15R, 2 x NEMA 5-20R |
| Protection Type | Spike Protection, Surge Protection |
| Filters | EMI Filter, RFI Filter |
Power Description
| Field | Details |
|---|---|
| Input Voltage | 120 V AC |
| Power Rating (Watt) | 2880 W |
| Input Current | 24 A |
Physical Characteristics
| Field | Details |
|---|---|
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7 in / 43.18 mm |
| Width | 19 in / 482.6 mm |
| Depth | 7 in / 177.8 mm |
Other Information
| Field | Details |
|---|---|
| Product Family | ePDU |
