Eaton Managed rack PDU, 0U, L5-30P input, 2.88 kW max, 120V, 24A, 10 foot cord, Single-phase

Add to Wishlist

Quick tech specs

  • Managed rackmount PDU monitors/manages/provide- s reliable/cost effective power distribution to connected mission critical equipment
  • Vertical power distribution unit supports 0U vertical mounting in most EIA-standard 19 inch racks
  • Wide operating temperatures (32-140 F)
  • Versatile rack-mountable single-phase PDU with built-in Ethernet interface helps monitor load levels to prevent overloads that cause downtime
  • 24 NEMA 5-20R Outlets and L5-30P Input w/ 10ft cord

AED11,699.00

Add to Wishlist

Know your gear

Eaton ePDU G3 Managed technology provides a best-in-class design featuring billing grade accuracy monitoring at the outlet level on a local LCD pixel display or over a network connection. The high accuracy meter will measure current, voltage, power and energy for load balancing, capacity planning, efficiency monitoring and energy usage reporting. Outlet switching allows for on, off or reboot of individual outlets, which reduces the cost of managing remote or local IT data center environments. The robust design is UL rated to operate at 140 degrees F (60 degrees C) ambient operating temperature for containment and high temperature environments.
SKU: EMA108-10 Category: Tag:
Overview
Attribute
Value
Brand Eaton
Product Line Eaton ePDU G3
Model Managed rack PDU, 0U, L5-30P input, 2.88 kW max, 120V, 24A, 10 foot cord, Single-phase
Manufacturer Powerware Systems
Network & Communication
Attribute Value
Remote Management Interface Ethernet 10/100, RS-232
Connectivity
Attribute Value
Input Connectors 1
Interface Provided 1 x management (Ethernet) – RJ-45, 1 x management (RS-232) – RJ-45
Power
Attribute Value
Emergency Power Off LCD display, Vertical orientation, Voltage monitoring
Frequency 50 – 60 hertz
Input Connector Type Power NEMA L5-30
Max Input Current 24 ampere
Output Connector Quantity 24
Power Output Connectors Details 24 x power NEMA 5-20R
Power Provided 2.88 kilograms per millimetere
Required Voltage AC 120 volt
Technical Information
Attribute Value
Form Factor (Power Device) Rack-mountable
Max Operating Temperature 140 degree Fahrenheit
Min Operating Temperature 32 degree Fahrenheit
Protection Type Circuit breaker
Product Information
Attribute Value
Packaged Quantity 1
Product Type Power distribution unit
Subcategory Power distribution devices
Included Items
Attribute Value
Cables Power cable – integrated – 10 ft
Dimensions & Weight
Attribute Value
Height 66.5 inch
Height (Rack Units) 38
Width 2 inch
Depth 2.6 inch
Physical Characteristics
Attribute Value
Color Black
Color Category Black
