Eaton Managed rack PDU, 0U, L6-30P input, 5.76 kW max, 200-240V, 24A, 10 ft cord, Single-phase

Add to Wishlist

Quick tech specs

  • Rackmount PDU monitors/manages/provide- s reliable/cost effective power distribution to connected mission critical equipment
  • Vertical power distribution unit supports 0U vertical mounting in EIA-standard 19in. racks
  • Wide operating temperatures (32-140 F)
  • Versatile rack-mountable single-phase PDU with Ethernet interface helps monitor load levels to prevent overloads that cause downtime
  • 20 C13 Outlet grip/4 C19 Outlet grip and L6-30P Input with 10ft cord

AED10,899.00

Add to Wishlist

Know your gear

Eaton ePDU G3 Managed technology provides a best-in-class design featuring billing grade accuracy monitoring at the outlet level on a local LCD pixel display or over a network connection. The high accuracy meter will measure current, voltage, power and energy for load balancing, capacity planning, efficiency monitoring and energy usage reporting. Outlet switching allows for on, off or reboot of individual outlets, which reduces the cost of managing remote or local IT data center environments. The robust design is UL rated to operate at 140 degrees F (60 degrees C) ambient operating temperature for containment and high temperature environments.
SKU: EMA107-10 Category: Tag:
Category Specification
Overview
Brand Eaton
Product Line Eaton ePDU G3
Model Managed
Manufacturer Powerware Systems
Network & Communication
Remote Management Interface Ethernet 10/100, RS-232
Connectivity
Input Connectors 1
Interface Provided 1 x management (Ethernet) – RJ-45, 1 x management (RS-232) – RJ-45
Power
Emergency Power Off LCD display, Vertical orientation, Voltage monitoring
Frequency 50 – 60 hertz
Input Connector Type Power NEMA L6-30
Max Input Current 24 ampere
Output Connector Quantity 24
Power Output Connectors Details 20 x power IEC 60320 C13, 4 x power IEC 60320 C19
Power Provided 5.76 kilograms per millimetere
Required Voltage AC 200-240 volt
Technical Information
Form Factor (Power Device) Rack-mountable
Max Operating Temperature 140 degree Fahrenheit
Min Operating Temperature 32 degree Fahrenheit
Protection Type Circuit breaker
Product Information
Packaged Quantity 1
Product Type Power distribution unit
Subcategory Power distribution devices
Included Items
Cables Power cable – integrated – 10 ft
Dimensions & Weight
Height 66.5 inch
Height (Rack Units) 38
Width 2 inch
Depth 2.1 inch
Physical Characteristics
Color Black
Color Category Black
