Eaton Tripp Lite Series 2.9kW 120V Single-Phase ATS/Monitored PDU – 24 5-15/20R & 1 L5-30R Outlets, Dual L5-30P Inputs,


quick tech specs

  • ATS PDU allows real-time current metering and remote power monitoring to help prevent circuit overloads and ensure proper load balance
  • Enables redundant A/B power option for single-corded network devices
  • Dual 10ft cords w/ NEMA L5-30P inputs connect to separate power sources
  • Tripp Lite is now part of Eaton
  • Digital meter for real-time voltage/amp and load monitoring helps prevent overloads
  • TAA Compliant PDU

AED7,699.00

Know your gear

Single-Phase 30A ATS PDU Distributes and Monitors Network-Grade Power in Real Time
This monitored PDU provides real-time remote monitoring of voltage, frequency and load levels via its built-in network interface. Ideal for network IT applications, small computer rooms and other equipment rack applications, the PDUMNH30AT2 features 24 NEMA 5-15/20R 120V outlets and one NEMA L5-30R outlet, which distribute AC power to rack equipment. Dual 10-foot (3.1-meter) power cords with NEMA L5-30P inputs connect to separate primary and secondary mains circuits, backup generators, UPS systems or utility power grids, including out-of-phase sources.
Switches from Primary to Secondary Power Source in Milliseconds
Dynamic solid-state automatic transfer switching (ATS) allows the PDU to switch to the secondary source within 1–5 milliseconds, should the primary source fail or become unstable, to ensure your connected equipment operates without interruption. An on-board ATS processor constantly evaluates the power quality of both input sources. It prevents switching if the secondary source is unavailable or of lower quality than the primary source.
The HTML5-based WEBCARDLX network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. The latest version of PowerAlert Device Manager (PADM20) provides enhanced remote management capabilities, including customizable dashboard graphs to fit user preferences. The PADM20 upgrade and Tripp Lite’s PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large installations, including firmware update checks and backup and restoration of device configurations.
Digital LED Display and Load Meter Helps Prevent Potentially Expensive Overloads
A three-digit LED display shows measured or calculated amperage, kilowatt and voltage values at a glance. Monitoring amperage helps ensure load levels remain well below maximum capacity with no danger of overload that could lead to costly downtime or damaged equipment. Maintaining proper load levels, even while adding new equipment, can keep your TCO (total cost of ownership) low. Monitoring current provides 1% billing grade accuracy.
Mounts into 2U of Rack Space or on a Wall
Use the included mounting hardware to install the all-metal housing into 2U of space in an EIA-standard 19-inch rack. You may also use the mounting brackets to secure the PDU to a wall or under a counter. Included cord retention brackets help organize connected power cords and eliminate cable clutter.
TAA-Compliant for GSA Schedule Purchases
The PDUMNH30AT2 is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
SKU: PDUMNH30AT2 Category: Tag:
Overview
Specification Details
Brand Tripp Lite
Product Line Eaton Tripp Lite Series
Model 2.9kW 120V Single-Phase ATS/Monitored PDU – 24 5-15/20R & 1 L5-30R Outlets, Dual L5-30P Inputs, 10 ft. Cords, 2U, TAA
Manufacturer Tripp Lite
Network & Communication
Specification Details
Remote Management SNMP, SSH, Telnet
Remote Management Interface Ethernet 10/100
Connectivity
Specification Details
Input Connectors 2
Interface Provided 1 x management (Fast Ethernet) – RJ-45
graphql
CopyEdit
Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā  1 x management (USB) – 4 pin USB Type AĀ Ā
Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā  1 x management (USB) – Micro-USB Type BĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā  |
Power
Specification Details
Emergency Power Off Automatic Transfer Switch (ATS), Built-in LX platform interface, Current meter, LED display, Overload protection
Frequency Provided 50/60 hertz
Input Connector Type Power NEMA L5-30P
Input Wiring 1-phase
Max Input Current 30 ampere
Output Connector Quantity 25
Output Connector Type 24 x power NEMA 5-15/20R, Power NEMA L5-30R
Power Output Connectors Details 1 x power NEMA L5-30R, 24 x power NEMA 5-15/20R
Power Provided 3.05 kilograms per millimetere
Provided Voltage AC 100/120/127 volt
Required Voltage AC 100/120/127 volt
Technical Information
Specification Details
Form Factor Rack-mountable
Max Operating Temperature 104 degree Fahrenheit
Min Operating Temperature 32 degree Fahrenheit
Operating Humidity 5 – 95% (non-condensing)
Product Information
Specification Details
Cord Length 10 ft
Features Auto-switching, Horizontal orientation, SNMP support
Packaged Quantity 1
Product Type Power distribution unit
Rack Mounting Kit Included
Subcategory Power distribution devices
Included Items
Specification Details
Cables 2 x power cable (NEMA L5-30P) – integrated – 10 ft
| Included Accessories | 24 cable ties, 4 x cable retention brackets |
Dimensions & Weight
Specification Details
Height 3.4 inch
Height (Rack Units) 2
Rack Size 16.9″
Rack Size (metric) 42.93 cm
Weight 13.71 lbs
Width 17.3 inch
Depth 11.9 inch
Physical Characteristics
Specification Details
Color Category Black
