EATON Tripp Lite Series 2000W Power Inverter/Charger 12VDC, Auto-Transfer Switching


  • Extended Run UPS Configure as a UPS for long-term battery support of telecom systems, security alarms, computer systems and various other motorized and electronic loads.
  • Standalone Power Alternative power source for use in off-grid, backwoods, alternative energy and export applications where commercial power is not continuously available.
  • Automotive Connect to an automotive electrical system to run power tools, computers, electronic test equipment, home entertainment and other AC appliances in fleet service vehicles, over-the-road trucks, campers, RVs, minivans and more.
  • Allows unlimited runtime capability by allowing the use any number of user-supplied batteries
  • Frequency control for operating stability
  • User supplies cabling, 4 gauge or larger recommended
  • Cooling Method: Fan
  • Auto-transfer to enable battery charging and automatic UPS support for blackouts and brownouts
  • RJ45 port allows connection of APS remote switch
  • Battery runtime is dependent upon the size and number of user-supplied batteries in 12V configuration
  • Advanced 20/60 amp selectable , 3-stage battery charger and selector switch for gel or wet cell batteries
  • Resettable circuit breaker protects APS against system overload

AED11,699.00

The APS2012 2000W PowerVerter APS 12V DC 120V AC Inverter/Charger is a reliable power source for a wide variety of equipment ranging from power tools and pumps to portable lighting and computer equipment in heavy-load conditions. With no fumes, fuel or excess noise, it’s an excellent alternative to generator power. The DC-to-AC inverter features an automatic line-to-battery transfer switch and integrated charging system that allow it to work as a vehicle inverter, standalone AC power source or extended-run UPS. It delivers 2000W of continuous power, 3000W up to one hour, or 4000W of peak power up to 10 seconds during equipment startup or cycling. An automatic overload detector, cooling fan and resettable AC circuit breakers protect the unit from damage. Designed for easy installation in RVs, commercial and fleet vehicles, emergency vehicles and construction equipment, the APS2012 converts stored power from any 12V battery or automotive DC source to safe, stable, computer-grade AC power for unlimited runtime. When hardwired to an external 120V AC source, the unit keeps the user-supplied battery charged via a three-stage 25/100A selectable charging system while simultaneously delivering AC power to connected equipment. When used as a UPS, the APS2012 responds to blackouts and brownouts with an automatic, instantaneous transfer to battery-derived AC output. LEDs on the unit indicate load level, battery charge level, shutdown status and system fault status.

SKU: APS2012 Category: Tag:
Category Attribute Details
General Information Product Name Tripp Lite Series 2000W Power Inverter/Charger 12VDC, Auto-Transfer Switching
Manufacturer Part Number APS2012
Product Line PowerVerter
Product Series APS
Product Type Power Inverter
Technical Information Plug / Connector Type Hardwired
Receptacles Hardwired
Power Description Input Voltage 12 V DC
Output Voltage 120 V AC
Maximum Frequency 60 Hz
Peak Power Load 4000 W
Continuous Power Load 2000 W
Waveform Type Pulse-width Modulated Sine Wave
Physical Characteristics Height 7.3″
Width 8.5″
Depth 16.3″
Miscellaneous Country of Origin China
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Other Information Product Color Black
Color Family Black
Input Voltage Range 10 V DC – 15 V DC
