Eaton Tripp Lite Series PDU Basic 208V / 240V 30A 6 C19; 32 C13 L6-30P Vertical 0URM
- Basic 0U 63.75 in. vertical rack PDU
- 208/240V 30A maximum capacity
- 10 ft. input cable with locking L6-30P plug
- 38 total output receptacles (6 C19
- Toolless button-mount installation
- Cord retention brackets keep vital equipment plugs connected
AED3,799.00
Tripp Lite Basic Power Distribution Units give IT Managers the ability to power multiple servers and vital networking hardware from a single input power source. Switch-free unfiltered electrical pass-through reliably distributes UPS or generator power to critical equipment in rack enclosures, network closets and more. Tooless mounting enables simple installation in button-mount compatible racks. Included mounting brackets support vertical installation in standard 2 and 4 post racks or other surfaces, such as under-counter or wallmount configurations. Plug retention brackets keep vital equipment plugged in and continuously powered.PDUV30HV 63.75 in. vertical 0U rack PDU supports 30A maximum capacity at 208/240V (agency derated to 24A). Includes 10 ft. attached line cord with L6-30P input plug. 32 C13 and 6 C19 outlets support up to 38 directly connected pieces of networking equipment. Outlets are arranged in two separately breakered 15A load banks.
| Category | Attribute | Details |
|---|
| General Information | Product Name | Tripp Lite Series PDU Basic 208V / 240V 30A 6 C19; 32 C13 L6-30P Vertical 0URM |
| Product Model | PDUV30HV |
| Product Type | PDU |
| Technical Information | PDU Type | Basic |
| Plug / Connector Type | NEMA L6-30P |
| Receptacle Type | IEC 60320 C19, IEC 60320 C13 |
| Receptacle Detail | 6 x IEC 60320 C19 32 x IEC 60320 C13 |
| Protection Type | Overload Protection, Short Circuit Protection |
| Power Description | Input Voltage | 230 V AC |
| Input Voltage Range | 208 V AC – 240 V AC |
| Output Voltage | 208 V AC, 240 V AC |
| Physical Characteristics | Mounting Orientation | Vertical |
| Mount Type | Wall-mountable, Rack-mountable |
| Height | 63.8″ |
| Width | 2.3″ |
| Depth | 3.8″ |
