Overview |
|
Brand |
Epson |
Product Line |
Epson SureColor |
Model |
P6570DE |
Manufacturer |
Epson UMRP |
Memory |
|
RAM Installed |
4 GB |
Connectivity |
|
Interface |
Gigabit LAN, USB 3.0, Wi-Fi(ac) |
Interface Required Connections |
1 Ć Gigabit LAN (RJ-45), 1 Ć USB 3.0 |
Printing |
|
Color |
6-ink |
Duplex Printing |
None |
Image Enhancement Technology |
Epson Variable-sized Droplet Technology |
Ink Cartridge Configuration |
6 cartridges (cyan, magenta, yellow, gray, photo black, matte black) |
Ink Palette Supported |
Cyan, magenta, yellow, photo black, matte black, gray |
Ink Type |
Epson UltraChrome PRO6 |
Inkjet Technology |
Epson PrecisionCore MicroTFP |
Max B/W Print Resolution |
2400 Ć 1200 dpi |
Max Color Print Resolution |
2400 Ć 1200 dpi |
Max H-Document Size |
24 in |
Max Print Length |
298 ft |
Max Print Size |
Roll (24 in) |
Max Resolution Class B/W |
2400 Ć 1200 dpi |
Max Resolution Class Color |
2400 Ć 1200 dpi |
Media Thickness Range |
0.0028 in ā 0.0315 in |
Min H-Document Size |
8 in |
Minimum Ink Droplet Size |
3.5 pl |
Mobile Device Printing |
Epson Cloud Solution PORT |
Photo Printing |
Yes |
Print Output Type |
Color |
Wireless Print Technology |
Wired, Wireless |
Wireless Print Technology Ready |
Yes |
Media Types & Handling |
|
Large Format Printer Size |
24″ (610 mm) |
Media Feeders |
1 Ć automatic ā 1 roll (24 in) |
Media Size Class |
Other |
Media Sizes |
Roll (10 in), Roll (13 in), Roll (14 in), Roll (17 in), Roll (20 in), Roll (24 in) |
Media Type |
Other, Plain paper |
Display & Graphics |
|
Touchscreen |
No |
Power |
|
Frequency |
50/60 Hz |
Power Consumption Operational |
75 W |
Power Device Type |
Power supply |
Required Voltage |
AC 110ā240 V |
Sleep-Mode Power Consumption |
2 W |
Software |
|
Software Type |
Epson Device Admin, Epson Edge Dashboard, Epson Media Installer, Epson Print Admin, EpsonNet Config, EpsonNet Print, EpsonNet Setup |
Technical Information |
|
Auto Paper Cutter |
Yes |
Power Device Form Factor |
Internal |
Language Emulation |
EPSON ESC/P, EPSON ESC/P Raster, HP GL/2, HP RTL |
Max Operating Temperature |
95 °F |
Min Operating Temperature |
50 °F |
Operating Humidity |
20 ā 80% (non-condensing) |
Operating System Required |
macOS 10.9.5 or later (incl. macOS 11+), Windows XP (32/64-bit) through Windows 10, Windows Server 2003 SP2+ through Server 2019 |
Sound Emission (Operating) |
49.6 dBA |
Product Information |
|
Built-in Devices |
Touch screen |
Office Machine Type |
Printer |
Printer Product Type |
Large-format printer |
Scanner Functionality |
None |
Printer Functions |
Printer |
Packaged Quantity |
1 |
Preview Screen Size |
4.3″ (10.9 cm) |
Print Technology |
Inkjet |
Printer Features |
Auto take up reel, Borderless printing |
Included Items |
|
Consumables Included |
6 Ć ink cartridges (cyan, magenta, yellow, gray, photo black, matte black) ā 240 ml each |
Printer Accessories Included |
2 roll adapters, Start Here poster |
Dimensions & Weight |
|
Height |
38.4 in |
Width |
54 in |
Depth |
20 in |
Weight |
253.53 lbs |
Physical Characteristics |
|
Color Category |
Black, White |
Certifications & Listings |
|
Compliant Standards |
FCC Class B certified, NRTL, RoHS, UL/CSA 62368-1 |
Energy Star |
Yes |
ENERGY STAR Certified |
No |
EPEAT Compliant |
No |
TCO Certified |
No |
Energy & Performance |
|
Standby Power Consumption |
0.3 W |
