Epson delivers a first-of-its-kind design that redefines speed, versatility and efficiency for its class: the SureColor T7770DL. Having the smallest footprint in its class – up to 25% smaller than its competition – and full-front operation means the T7770DL fits where other printers don’t. It’s designed for outstanding quality, sharpness and speed, generating technical drawings at production-class speeds over 1,400 ft./hr., A1/D-size prints in as little as 16 seconds, and graphics at speeds up to 300 ft./hr. Its innovative UltraChrome XD3 six-ink set with dedicated Red Ink opens the door to both an extraordinary color gamut for a production printer and rich red branding colors. This high-quality printer provides over double the ink capacity of previous generations for a remarkably low ink cost per milliliter, as well as helps minimize waste when compared to Epson SureColor T-Series cartridge systems. And simple, carefree operation combined with new levels of versatility and media flexibility helps users do more using less space – all with a low total cost of ownership. Add it all up, and this is not just a one-of-a-kind printer: it’s the new benchmark in high-speed CAD and graphics.
Printers & Supplies
Epson SureColor T7770DL – large-format printer – color – ink-jet
Quick tech specs
- 44″ large-format printer
- ink-jet
- up to 1399.3 sq.ft/hour (mono) / up to 1399.3 sq.ft/hour (color)
- USB 3.0, Gigabit LAN, Wi-Fi(ac)
- color
- – 2400 x 1200 dpi
- capacity: 2 rolls
- cutter
AED56,699.00
Category | Specification |
---|---|
Overview | |
Brand | Epson |
Product Line | Epson SureColor |
Model | T7770DL |
Manufacturer | Epson UMRP |
Memory | |
RAM Installed | 4 GB |
Network & Communication | |
Product Type | Print server |
Connectivity | |
Interface | Gigabit LAN, USB 3.0, Wi-Fi(ac) |
Interface Required Connections | 1 x Gigabit LAN, 1 x USB 3.0 |
Printing | |
Borderless Photo Sizes | Roll (10, 13, 16, 17, 20, 24, 36, 44 in) |
Color | 6-ink |
Image Enhancement Technology | EPSON Variable-sized Droplet Technology |
Ink Cartridge Configuration | 6 individual ink tanks |
Ink Palette Supported | Cyan, Magenta, Yellow, Red, Photo Black, Matte Black |
Ink Type | Epson UltraChrome XD3 Ink |
Inkjet Technology | Epson PrecisionCore MicroTFP |
Max B/W Print Resolution | 2400 x 1200 dpi |
Max Color Print Resolution | 2400 x 1200 dpi |
Max Color Print Speed | 1399.3 sq.ft/hour |
Max Mono Print Speed | 1399.3 sq.ft/hour |
Max Print Size | Roll (44 in) |
Max H-Document Size | 44 in |
Min H-Document Size | 8 in |
Min V-Document Size | 8 in |
Media Capacity | 2 rolls |
Media Thickness Range | up to 0.06 in |
Minimum Ink Droplet Size | 3.5 pl |
Nozzle Configuration | 6 x 1600 nozzles |
Print Output Type | Color |
Print Speed | Up to 0.3 min/page (A1), Up to 1399.3 sq.ft/hour (B0), Up to 300.3 sq.ft/hour |
Wireless Print Technology | Wired, Wireless |
Wireless Print Technology Ready | Yes |
Media Types & Handling | |
Large Format Printer Size | 44″ (1118 mm) |
Media Feeders | 2 x manual – Roll (44 in) |
Media Sizes | A1 (23.4 x 33.1 in), B0 (39.37 x 55.67 in), Roll (25.4 ā 111.8 cm) |
Media Type | Continuous paper, Plain paper, Poster board, Other |
Power | |
Frequency | 50/60 Hz |
Power Consumption (Operational) | 75 W |
Sleep-Mode Power Consumption | 2 W |
Required Voltage | AC 110-240 V |
Power Device Type | Power supply |
Software | |
Software Type | Drivers & Utilities |
Technical Information | |
Auto Paper Cutter | Yes |
Language Emulation | Adobe PostScript 3, EPSON ESC/P Raster, HP GL/2, HP RTL, PDF 1.7 |
Max Operating Temperature | 95°F |
Min Operating Temperature | 50°F |
Operating Humidity | 20 – 80% (non-condensing) |
Operating System Required | Windows XPā11, Windows Server 2003ā2019, macOS 10.9.5 or later, macOS 11+ |
Sound Emission (Operating) | 49.6 dBA |
Product Information | |
Built-in Devices | 4.3″ LCD touch screen |
Office Machine Type | Printer |
Printer Product Type | Large-format printer |
Scanner Functionality | None |
Printer Functions | Printer |
Packaged Quantity | 1 |
Print Technology | Inkjet |
Printer Features | Auto take up reel, Replaceable Ink Pack System (RIPS) |
Included Items | |
Consumables Included | 1 x maintenance box |
Printer Accessories Included | 2 roll adapters, Start here poster, USB stick |
Dimensions & Weight | |
Height | 38.4 in |
Width | 72.8 in |
Depth | 19.6 in |
Weight | 363.76 lbs |
Physical Characteristics | |
Color Category | Black, White |
Certifications & Listings | |
Compliant Standards | FCC Class B, NRTL, RoHS, UL/CSA/EN 62368-1 |
Energy Star | Yes |
ENERGY STAR Certified | No |
EPEAT Compliant | No |
TCO Certified | No |
Energy & Performance | |
Standby Power Consumption | 32 W |
