Extreme Networks ExtremeSwitching 220 Series 220-12p-10GE2 – switch – 12 ports – managed – rack-mountable

Add to Wishlist

Quick tech specs

  • 12p-10GE2
  • L3
  • 12 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+
  • PoE+ (123 W)
  • Switch
  • managed
  • desktop, rack-mountable

AED7,899.00

Add to Wishlist

Know your gear

The ExtremeSwitching 220 Series is an economical, fixed-configuration family of Gigabit Ethernet Layer 2/3 switches designed for enterprises, branch offices and small to medium-sized businesses looking for key features in a flexible, yet easy-to-manage solution.

The 220 Series also provides multiple management options, including cloud-based management via ExtremeCloud for wired and wireless network oversight through a single pane of glass. The switches can also be set-up via a web browser, or managed by ExtremeManagement for centralized provisioning, monitoring and troubleshooting. And for advanced users, the 220 Series offers an industry-standard CLI along with scripting capabilities.

SKU: 16561 Category: Tag:
Overview
Brand Extreme Networks
Product Line Extreme Networks ExtremeSwitching 220 Series
Model 220-12p-10GE2
Manufacturer EXTREME NETWORKS
Processor
Clock Speed 1 GHz
Processor Brand ARM
Processor Type Cortex-A9
Processors Installed 1
Memory
Flash Memory Installed 128 megabyte
RAM Installed 512 megabyte
Network & Communication
Advanced Switching Layer 3
Compliant Standards IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad (LACP), IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Features 1.5MB packet buffer, Access Control List (ACL) support, ARP support, AAA, BFD, Broadcast Storm Control, CoS, DHCP relay, DHCP snooping, DiffServ, ECMP, Flow control, GVRP, GMRP, Guest VLAN, IGMP snooping, Jumbo Frames support, Link Aggregation, LLDP, LLDP-MED, MAC address filtering, MSTP, QoS, RSTP support, STP, VLAN support, Voice VLAN
Form Factor (Hubs & Switches) Desktop, Rack-mountable
MAC Address Table Size 16,000 entries
Manageable Yes
Max Units In A Stack 4
PoE Budget 123 watt
Ports 12
Power Over Ethernet (PoE) PoE+
Product Type Switch
Remote Management CLI, HTTP, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 3, Telnet
Routing Protocol IGMP, RIP, RIP-2, Static IP routing, Static IPv6 routing
Stackable Yes
Subcategory Network hubs and switches
Switching Type Gigabit Ethernet
Connectivity
Interface Provided 1 x management (LAN) RJ-45, 1 x serial RJ-45, 12 x 1000Base-T RJ-45 PoE+, 2 x 10GBase-X SFP+
Port Quantity 12
Port Type 10/100/1000 (PoE+)
Ports Type (2nd) 10 Gigabit SFP+
Power
Power Consumption Operational 155 watt
Redundant Power Supply Optional
Technical Information
Encryption SSL 3.0, TLS 1.0
Humidity Range Storage 10 – 95% (non-condensing)
Max Operating Temperature 122 degree Fahrenheit
Max Storage Temperature 158 degree Fahrenheit
Min Operating Temperature 32 degree Fahrenheit
Min Storage Temperature -40 degree Fahrenheit
Operating Humidity 10 – 95% (non-condensing)
Product Information
Authentication Method RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+
Capacity ACL: 100, IPv6 routes (static): 64, LAG groups: 6, Traffic classes (queues): 8, VLANs supported: 1024
Device Type Internal power supply
Packaged Quantity 1
Performance Switching throughput: 47.6 Mpps, Switching throughput: 64 Gbps
Ports (2nd) Quantity 2
Dimensions & Weight
Height 1.7 inch
Height (Rack Units) 1
Weight 4.14 lbs
Width 8.2 inch
Depth 10 inch
Physical Characteristics
Color Category Black
