Extreme Networks ExtremeSwitching X440-G2 X440-G2-24t-10GE4-DC – switch – 24 ports – managed – rack-mountable
Extreme Networks ExtremeSwitching X440-G2 X440-G2-24t-10GE4-DC – Switch – managed – 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ + 4 x combo SFP – rack-mountable
15,099.00 د.إ
The ExtremeSwitching X440-G2 series is based on Extreme Networks ExtremeXOS, a highly resilient OS that provides continuous uptime, manageability and operational efficiency. Each switch offers the same high-performance, non-blocking hardware technology, in the Extreme Networks tradition of simplifying network deployments through the use of common hardware and software throughout the network. The ExtremeSwitching X440-G2 switches are cost-effective campus edge switches with IEEE 802.3at PoE-plus.
| General | |
|---|---|
| Device Type | Switch – 24 ports – managed – stackable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ + 4 x combo SFP |
| Performance | Aggregate switching bandwidth: 128 Gbps<br>Forwarding performance: 95.2 Mpps<br>Latency (64-byte packets): 4 µs |
| Capacity | Virtual interfaces (VLANs): 4094<br>QoS hardware queues per port: 8 |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9216 bytes |
| Features | Traffic shaping, DoS attack prevention, CLEAR-Flow Security Rules Engine, 1.5MB packet buffer |
| Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az |
| Processor | X MIPS: 1 GHz |
| RAM | 1 GB DDR3 SDRAM |
| Flash Memory | 4 GB |
| Status Indicators | Port status, power, fan |
| Expansion / Connectivity | Interfaces<br>24 x 1000Base-T RJ-45<br>8 x 10GBase-X SFP+<br>1 x console RJ-45 management<br>1 x management (Gigabit LAN) RJ-45 |
| Power | Power Device: Internal power supply – hot-plug<br>Installed Qty: 1<br>Max Supported Qty: 2<br>Power Redundancy: Optional<br>Power Consumption Operational: 39 Watt<br>Features: Redundant Power System (RPS) connector |
| Miscellaneous | Compliant Standards: CISPR 22 Class A, CISPR 24, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-3, CCC, EMC, ICES-003 Class A, FCC, EN 61000-4-11, RoHS, CSA C22.2 No. 60950-1-03, UL 60950-1 Second Edition, KCC, WEEE, EN 60825-1, EN55024 Class A, CDRH, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, EN 61000-3-2:2006, EN 61000-3-3:2008, VCCI Class A, China RoHS, EN 61000-4-2:2009, EN 61000-4-5:2006, EN 61000-4-6:2009, RCM, EMC 2004/108/EC, LVD 2006/95/EC, 21 CFR 1040.10, IEC 61000-4-2:2008, IEC 61000-4-4:2004, IEC 61000-4-5:2005, IEC 61000-4-6:2008, EN 55022:2006+A1:2007 Class A, FCC CFR47 Part 15 A, ACMA |
| Software / System Requirements | Software Included: ExtremeXOS Edge |
| Dimensions & Weight | Width: 17.4 in<br>Depth: 10 in<br>Height: 1.7 in<br>Weight: 8.07 lbs |
| Environmental Parameters | Min Operating Temperature: 32 °F<br>Max Operating Temperature: 122 °F<br>Humidity Range Operating: 10 – 95% (non-condensing)<br>Min Storage Temperature: -40 °F<br>Max Storage Temperature: 158 °F<br>Humidity Range Storage: 10 – 95% (non-condensing) |
