Switches
Extreme Networks Virtual Services Platform 4900 Series VSP4900-12MXU-12XE – Bundle – switch – 12 ports – managed –
Quick tech specs
- Number of Port: 24
AED105,899.00
Know your gear
Simplify your network with the Extreme Networks VSP 4900 Fabric Connect Multi-service Edge Device. Designed to extend the reach of Extreme Fabric Connect technology to the branch and network edge, the Virtual Services Platform (VSP) 4900 Series delivers fully featured network virtualization capabilities in a cost-effective Ethernet platform. Optimized for remote sites and the network edge, it offers full multi-service capabilities while providing a simplified, streamlined way to build and manage networks.
| Category | Specification |
|---|
| Overview |
| Brand | Extreme Networks |
| Product Line | Extreme Networks Virtual Services Platform 4900 Series |
| Model | VSP4900-12MXU-12XE |
| Manufacturer | EXTREME NETWORKS |
| Processor |
| Processors Installed | 1 |
| Memory |
| Flash Memory Installed | 8 GB |
| RAM Installed | 2 GB |
| Network & Communication |
| Advanced Switching | Layer 3 |
| Compliant Standards | IEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1ag, IEEE 802.1ah, IEEE 802.1aq, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qbp, IEEE 802.1Qcj, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3at, IEEE 802.3ba, IEEE 802.3bm, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Features | 3 fans, ARP support, Auto-negotiation, Deep Packet Inspection (DPI), Full duplex capability, IPFIX, Link Aggregation Control Protocol (LACP), LRM optics support, Media Access Control Security (MACsec), Metallic Loop Testing for subscriber lines (MLT), Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Port-based VLAN, Quality of Service (QoS), Rapid Reconfiguration of Spanning Tree (RSTP), Remote Switch Port Analyzer (RSPAN), sFlow, Shortest Path Bridging (SPB), Support IP Shortcut Routing, Support Virtual Service Networks (VSN), Virtual Extensible LAN (VXLAN), Virtual Routing and Forwarding (VRF), VLAN support |
| Form Factor (Hubs & Switches) | Rack-mountable |
| MAC Address Table Size | 80K entries |
| Manageable | Yes |
| PoE Budget | 720 watt |
| Ports | 12 |
| Power Over Ethernet (PoE) | PoE |
| Product Type | Switch |
| Routing Protocol | BGP, BGP+, IGMP, IGMPv2, IGMPv3, OSPFv2, OSPFv3, PIM-SM, PIM-SSM, RIP-1, RIP-2, RIPng |
| Subcategory | Network hubs and switches |
| Switching Type | 10 Gigabit Ethernet |
| Expansion Slots |
| Expansion Slots | 1 (total) / 0 (free) x Versatile Interface Module (VIM) |
| Connectivity |
| Interface Provided | 1 x 1000Base-T RJ-45 management, 1 x console (micro-USB) Type A, 1 x serial (console) RJ-45 management, 12 x 1/10GBase-X SFP+, 12 x 100/1000/2.5G/5G/10G RJ-45, 2 x USB |
| Port Quantity | 12 |
| Port Type | 100/1000/2.5G/5G/10GBase-T (PoE+) |
| Ports Type (2nd) | 1 Gigabit / 10 Gigabit SFP+ |
| Power |
| Frequency | 50/60 hertz |
| Hot-Plug | Hot-plug |
| Power Consumption Operational | 73 watt |
| Power Provided | 1100 watt |
| Power Supplies Installed | 1 |
| Redundant Power Supply | Optional |
| Redundant Power Supply Supported | 1+1 (with optional power supply) |
| Technical Information |
| Humidity Range Storage | 10 – 95% (non-condensing) |
| Max Operating Temperature | 113 degree Fahrenheit |
| Max Storage Temperature | 158 degree Fahrenheit |
| Min Operating Temperature | 32 degree Fahrenheit |
| Min Storage Temperature | -40 degree Fahrenheit |
| Operating Humidity | 10 – 95% (non-condensing) |
| Operating System Required | VSP Operating System Software (VOSS) |
| Product Information |
| Airflow Direction | Front to back airflow |
| Capacity | ARP entries: 32000, BGP peers: 256, BGPv6 peers: 256, IGMP interfaces: 4059, IP multicast streams: 6000, IP shortcut routes (IPv4): 15488, IP shortcut routes (IPv6): 7488, IPv4 routes: 15488, IPv6 neighbor table entries: 8000, IPv6 routes: 7744, L2 multicast virtual service networks: 2000, L2 virtual service networks: 4059, L3 multicast virtual service networks: 256, L3 virtual service networks: 256, LACP links per group (active): 8, MAC addresses: 40000, MLD interfaces: 4059, MSTP instances: 12, OSPF interfaces: 500, OSPFv3 interfaces: 500, PIM active interfaces: 128, RIP interfaces: 200, RIPng interfaces: 48, VLANs supported: 4059, VRF instances: 256 |
| Device Type | Internal power supply |
| Kit | Bundle |
| Packaged Quantity | 1 |
| Ports (2nd) Quantity | 12 |
| Rack Mounting Kit | Included |
| Dimensions & Weight |
| Height | 1.7 inch |
| Height (Rack Units) | 1 |
| Weight | 16.71 lbs |
| Width | 17.3 inch |
| Depth | 19.2 inch |
| Physical Characteristics |
| Color Category | Purple |
| Certifications & Listings |
| Compliant Standards | ACMA RCM, AS/NZS 60950-1, AS/NZS CISPR 32, ASTM D3580, BSMI, CAN/CSA-C22.2 No. 60950-1, CAN/CSA-C22.2 No. 62368-1, CB, CCC, CDRH, China RoHS SJ/T 11363-2006, CISPR 11 class A, CISPR 24:2010 Class A, CISPR 32 Class A, CNS 14336-1, EAC, EMC 2014/30/EU, EN 300 386 V1.6.1, EN 55011 class A, EN 55032 Class A, EN 60825-1 Class 1, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 62368-1, EN/ETSI 300 019-2-1 v2.1.2, EN/ETSI 300 753, EN55024, ETSI EN 300 019-2-2 V2.1.2, ETSI EN 300 019-2-3 V2.1.2, FCC CFR21 Part 1040.10, FCC CFR47 Part 15 B Class A, GB 4943.1-2011, GB 9254, ICES-003 Class A, IEC 60950-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, KCC, LVD 2014/35/EU, NRCS, RoHS 2011/65/EU, RoHS CNS 15663, SABS, UL 60950-1, UL 62368-1, VCCI Class A, WEEE 2012/19/EU |
| ENERGY STAR Certified | No |
| EPEAT Compliant | No |
| TCO Certified | No |
