FAP-221E – Fortinet FortiAP Access Points

Add to Wishlist

AED1,099.00

Add to Wishlist

FAP-221E Overview

FortiAP access points are managed centrally by the integrated WLAN controller of any FortiGate® security appliance or can be managed through the free FortiCloud provisioning and management portal.

Quick Specs

Figure 1 shows the appearance of FAP-221E.

FAP-221E
Table 1 shows the Quick Specs.

Product Code FAP-221E
Length x Width x Height 6.3 x 6.3 x 1.85 inches(160 x 160 x 47 mm)
Hardware Type Indoor AP
Number of Radios 2 + 1 BT/BLE
Number of Antennas 4 Internal + 1 Internal BT/BLE
Antenna Type and Peak Gain PIFA: 4 dBi for 2.4 GHz, 5 dBi for 5 GHz
Frequency Bands (GHz) 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725,5.725–5.850
Radio 1 Capabilities 2.4 GHz b/g/n (2×2:2 stream)

20/40 MHz (256 QAM)
Radio 2 Capabilities 5 GHz a/n/ac (2×2:2 stream)

20/40/80 MHz (256 QAM)
Maximum Data Rate Radio 1: up to 400 Mbps

Radio 2: up to 867 Mbps

Product Details

Fortinet FortiAP Series provides these features:

• Unified Management

Unified management console simplifies operations, ensuring consistent and effective policy enforcement and compliance.

• Advanced Security Protection

Wireless LAN security done right, from the leader in network security. Integrated Firewall, IPS, Application Control, and Web Filtering protect the wireless LAN from the latest security threats.

• Built-in Wi-Fi Security

Protects the network from advanced wireless threats and satisfies PCI DSS compliance.

FortiAP 221E provide these highlights:

– 802.11ac Wave 2

– Dual Radio 2.4 and 5 GHz

– 4 Internal/External Antennas

– 2×2 MU-MIMO

– Up to 400 + 867 Mbps

Compare to Similar Items

Table 2 shows the comparison.

Product Code FAP-221E FAP-421E
Length x Width x Height 6.3 x 6.3 x 1.85 inches(160 x 160 x 47 mm) 8.5 x 8.5 x 2.2 inches (215 x 215 x 56 mm)
Hardware Type Indoor AP Indoor AP
Number of Radios 2 + 1 BT/BLE 2
Number of Antennas 4 Internal + 1 Internal BT/BLE 8 Internal
Radio 1 Capabilities 2.4 GHz b/g/n (2×2:2 stream)

20/40 MHz (256 QAM)

 2.4 GHz b/g/n (4×4:4 stream) 20/40 MHz (256 QAM)
Radio 2 Capabilities 5 GHz a/n/ac (2×2:2 stream)

20/40/80 MHz (256 QAM)

 5 GHz a/n/ac (4×4:4 stream) 20/40/80 MHz (256 QAM)
Maximum Data Rate Radio 1: up to 400 Mbps

Radio 2: up to 867 Mbps

 Radio 1: up to 800 Mbps

Radio 2: up to 1,733 Mbps
Bluetooth Low Energy (BT/BLE) Radio Bluetooth scanning and iBeacon advertisement @ 4 dBm max TX power \
SKU: FAP-221E Category: Tag:

FAP-221E Specification

FAP-221E Specification

Hardware
Hardware Type Indoor AP
Number of Radios 2 + 1 BT/BLE
Number of Antennas 4 Internal + 1 Internal BT/BLE
Antenna Type and Peak Gain PIFA: 4 dBi for 2.4 GHz, 5 dBi for 5 GHz
Frequency Bands (GHz)* 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725,5.725–5.850
Radio 1 Capabilities 2.4 GHz b/g/n (2×2:2 stream)

20/40 MHz (256 QAM)
Radio 2 Capabilities 5 GHz a/n/ac (2×2:2 stream)

20/40/80 MHz (256 QAM)
Maximum Data Rate Radio 1: up to 400 Mbps

Radio 2: up to 867 Mbps
Bluetooth Low Energy (BT/BLE) Radio Bluetooth scanning and iBeacon advertisement @ 4 dBm max TX power
Interfaces 1x 10/100/1000 Base-T RJ45
Power over Ethernet (PoE) IEEE 802.3af
Simultaneous SSIDs 16 (14 if background scanning enabled)
EAP Type(s) EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST
User/Device Authentication WPA™ and WPA2™ with 802.1x or Preshared key, WEP,Web Captive Portal, MAC blacklist & whitelist
Maximum Tx Power 2.4 GHz: 23 dBm / 200 mW (2 chains combined)*

5 GHz: 24 dBm / 251 mW (2 chains combined)*
Kensington Lock Yes
IEEE Standards 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.1X,802.3af, 802.3az
SSID Types Supported Local-Bridge, Tunnel, Mesh
Per Radio Client Capacity Up to 512
Cellular Co-existence Yes
LED Off Mode Yes

Advanced 802.11 Features
802.11ac MU-MIMO Wave 2 Yes
Transmit Beam Forming (TxBF) Yes
Low-Density Parity Check (LDPC) Encoding Yes
Maximum Likelihood Demodulation (MLD) Yes
Maximum Ratio Combining (MRC) Yes
A-MPDU and A-MSDU Packet Aggregation Yes
MIMO Power Save Yes
Short Guard Interval Yes

Wireless Monitoring Capabilities
Rogue Scan Radio Modes Background, Full-time
WIPS / WIDS Radio Modes Background, Full-time
Packet Sniffer Mode Yes
Spectrum Analyzer Yes

Dimensions
Length x Width x Height 6.3 x 6.3 x 1.85 inches(160 x 160 x 47 mm)
Mounting Options Ceiling, T-Rail, and Wall
Included Accessories Mount kits for Ceiling, T-Rail, and Wall

Environment
Power Supply SP-FAP200-PA-XX, GPI-115,or GPI-130
Power Consumption (Max.) 12.36 W
Humidity 5–90% non-condensing
Operating / Storage Temperature -4–113°F (-20–45°C) /-40–158°F (-40–70°C)
Directives   Low Voltage Directive • RoHS
UL2043 Plenum Material Yes
Mean Time Between Failures >30 Years
IP Rating \
Surge Protection Built In \
Hit-less PoE Failover No

Certifications
Wi-Fi Alliance Certified Yes
DFS FCC, IC, CE, Japan, Taiwan

Warranty
Limited Lifetime Warranty Yes
* Frequency selection and power may be restricted to abide by regional regulatory compliance laws.
