Fortinet FortiGate 81F-POE – security appliance
Quick tech specs
- POE
- 1GbE
- Security appliance
- desktop / wall / rack mountable
AED10,299.00
Know your gear
The FortiGate FortiWiFi 80F series provides an application-centric, scalable, and secure SDWAN solution in a compact, fanless, desktop form factor for enterprise branch offices and midsized businesses with integrated Wi-Fi-6 (802.11ax). Protects against cyber threats with systemon-a-chip acceleration and industry-leading secure SD-WAN in a simple, affordable, and easy to deploy solution. Fortinet’s Security-Driven Networking approach provides tight integration of the network to the next generation of security.
| Category | Details |
|---|---|
| Overview | |
| Brand | Fortinet |
| Product Line | Fortinet FortiGate |
| Model | 81F-POE |
| Manufacturer | Fortinet |
| Processor | |
| Processor Brand | Fortinet |
| Processor Type | FortiASIC SOC4 |
| Processors Installed | 1 |
| Storage | |
| Hard Drive Capacity | 128 GB |
| Port Expansion Hard Drive Type | SSD |
| Installed Quantity | 1 |
| Network & Communication | |
| Connectivity Technology | Wired |
| Data Link Protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | 3G/4G USB Dongle Support, CAPWAP support, Fanless, SD-WAN support, SSL inspection, VPN support |
| Form Factor | Desktop / wall / rack mountable |
| Network Standard | HTTP, HTTPs, IPSec, TCP/IP, UDP/IP |
| Power Over Ethernet (PoE) | PoE+ |
| Product Type | Security appliance |
| Remote Management | HTTP, HTTPS |
| Status Indicators | Bypass, HA, Power, Status |
| Connectivity | |
| Interface Provided | 1 x console – RJ-45, 1 x USB 3.0 – Type A, 2 x 1000Base-T (FortiLink PoE+) – RJ-45, 2 x 1000Base-T/1000Base-X – RJ-45/SFP (mini-GBIC), 6 x 1000Base-T (PoE+) – RJ-45 |
| Power | |
| Frequency | 50/60 hertz |
| Power Supplies Installed | 1 |
| Power Supplies Supported | 2 |
| Redundant Power Supply | Optional |
| Required Voltage | AC 100-240 volt |
| Technical Information | |
| Encryption | 256-bit AES, 256-bit SHA, SSL, TLS 1.3 |
| Max Operating Temperature | 104 degree Fahrenheit |
| Min Operating Temperature | 32 degree Fahrenheit |
| Operating Humidity | 10 – 90% (non-condensing) |
| Product Information | |
| Capacity | Client to gateway IPSec VPN tunnels: 2500, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 1500000, Firewall policies: 5000, Gateway to gateway IPSec VPN tunnels: 200, Maximum virtual domains: 10, New TCP sessions per second: 45000, Number of FortiAP devices (tunnel): 48 |
| Device Type | External power adapter |
| Packaged Quantity | 1 |
| Network Device | Application control throughput: 1.8 Gbps, CAPWAP throughput: 9 Gbps, Firewall latency (64-byte UDP): 3.23 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 7 Gbps, Firewall throughput: 10.5 Mpps |
| VPN Throughput (512-bit IPSec) | 6.5 Gbps |
| VPN Throughput (SSL) | 950 Mbps |
| Dimensions & Weight | |
| Height | 2.4 inch |
| Weight | 3.09 lbs |
| Width | 8.5 inch |
| Depth | 7 inch |
| Physical Characteristics | |
| Color Category | White |
| Certifications & Listings | BSMI, CB, cUL, FCC, ICES, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, RCM, UL, VCCI |
