Fortinet FortiSwitch M426E-FPOE – switch – 16 ports – managed – rack-mountable

Add to Wishlist

Quick tech specs

  • 1U Rack-Mountable
  • Flash Storage: 256MB
  • SFP+ Ports Compatible
  • RAM: 1GB DDR4
  • Interface: 16xGE RJ45,8x 2.5GE RJ45,2x 5GE RJ45,4x 10GE SFP+,24-Port PoE

21,399.00 د.إ

Add to Wishlist

Know your gear

The Fortinet FortiSwitch M426E-FPOE Layer 2/3 FortiGate Switch delivers outstanding security, performance and manageability. Secure, simple and scalable, the FortiSwitch is ideal for threat conscious businesses of all sizes. Tightly integrated into the Fortinet Security Fabric via FortiLink, this switch can be managed directly from the familiar FortiGate interface. This single pane of glass management provides complete visibility and control of users and devices on the network regardless of how they connect, making it suitable for SD-Branch deployments with applications that range from desktop to data center aggregation, enabling businesses to converge their security and network access.

SKU: FS-M426E-FPOE Category: Tag:

Overview

Field Details
Brand Fortinet
Product Line Fortinet FortiSwitch
Model M426E-FPOE
Manufacturer Fortinet

Memory

Field Details
Flash Memory Installed 256 MB
Memory Technology DDR4 SDRAM
RAM Installed 1 GB

Network & Communication

Field Details
Advanced Switching Layer 3
Compliant Standards IEEE 802.1ab, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features Auto-negotiation, Auto-uplink, BPDU Guard, Cloud managed, DHCP client, DHCP snooping, DiffServ Code Point support, Flow control, IGMP snooping, IP forwarding, Link Aggregation, LLDP support, MIB II, Port mirroring, Private VLAN, sFlow, Spanning Tree Protocol (STP) support, Static routing, Storm Control, Syslog, Telnet server, ToS, VLAN Tagging
Form Factor Rack-mountable
Jumbo Frame Support Yes
MAC Address Table Size 16K entries
Manageable Yes
PoE Budget 420 watt
Ports 16
Power Over Ethernet (PoE) PoE++
Product Type Switch
Remote Management CLI, DHCP, HTTP, HTTPS, IPv4, IPv6, RADIUS, RSTP, SNMP 1/2c/3, SSH, Telnet, TFTP
Routing Protocol BFD, IGMP, MSTP, OSPFv2, RIP-2, RSTP, STP, VRRP
Status Indicators Status
Subcategory Network hubs and switches
Switching Type Gigabit Ethernet

Expansion Slots

Field Details
QSFP Slots 100/1000/2.5G/5G

Connectivity

Field Details
Interface Provided 1 x console RJ-45, 1 x management RJ-45, 16 x 1000Base-T RJ-45 PoE+, 2 x 1/5GBase-X RJ-45, 4 x 10GBase-X SFP+, 8 x 1/2.5GBase-T RJ-45 4PPoE
Port Quantity 16
Port Type 10/100/1000 (PoE+)
Ports Type (2nd) 100/1000/2.5G (PoE++)

Power

Field Details
Frequency 50/60 hertz
Power Consumption Operational 442 watt

Technical Information

Field Details
Max Operating Temperature 122°F
Max Storage Temperature 158°F
Min Operating Temperature 32°F
Min Storage Temperature -4°F
MTBF >10 Years
Operating Humidity 5 – 95% (non-condensing)

Product Information

Field Details
Authentication Method RADIUS, SSH
Capacity ACL entries: 512, Host entries: 4000, Link aggregation groups: 8, Packet buffer size: 2 MB, Routing entries: 64, VLANs: 4000
Device Type Internal power supply
Packaged Quantity 1
Performance Latency: 1 µs, Packets per second: 255 Mpps, Switching capacity: 172 Gbps
Ports (2nd) Quantity 8
Ports (3rd) Quantity 2
Ports (4th) Quantity 4
Ports (4th) Type 1 Gigabit / 10 Gigabit SFP+

Dimensions & Weight

Field Details
Height 1.7 inch
Height (Rack Units) 1
Weight 13.01 lbs
Width 17.3 inch
Depth 16.1 inch

Physical Characteristics

Field Details
Color Category White

Certifications & Listings

Field Details
Compliant Standards BSMI, CB, FCC, RCM, RoHS 2, UL, VCCI
ENERGY STAR Certified No
