| Device Type |
Security appliance |
| Width |
8.5 in |
| Depth |
6.3 in |
| Height |
1.5 in |
| Weight |
2.2 lbs |
| Processor / Memory / Storage |
|
| Processors Installed |
1 x Fortinet FortiASIC SOC4 |
| Networking |
|
| Form Factor |
Desktop |
| Connectivity Technology |
Wireless, wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Network / Transport Protocol |
IPSec |
| Frequency Band |
2.4 GHz, 5 GHz |
| Performance |
|
| IPS throughput |
1 Gbps |
| NGFW throughput |
800 Mbps |
| Threat protection throughput |
600 Mbps |
| VPN throughput (512-bit IPSec) |
4.4 Gbps |
| SSL inspection throughput |
310 Mbps |
| SSL inspection throughput |
320 connections per second |
| Firewall throughput (1518-byte UDP) |
5 Gbps |
| Firewall throughput (512-byte UDP) |
5 Gbps |
| Firewall throughput (64-byte UDP) |
5 Gbps |
| Firewall throughput |
7.5 Mpps |
| Application control (HTTP 64K) |
990 Mbps |
| VPN throughput (SSL) |
490 Mbps |
| CAPWAP throughput |
3.5 Gbps |
| Capacity |
|
| Latency |
4 µs |
| Concurrent sessions |
700,000 |
| New sessions |
35,000 |
| Firewall policies |
5,000 |
| Gateway to gateway IPSec VPN Tunnels |
200 |
| Client to gateway IPSec VPN tunnels |
250 |
| Virtual domains |
10 |
| Number of FortiSwitches |
8 |
| Number of FortiAP devices |
10 |
| Number of FortiToken devices |
500 |
| Concurrent SSL VPN users |
200 |
| SSL inspection concurrent sessions |
55,000 |
| Number of FortiClient devices |
200 |
| Status Indicators |
Link/activity |
| Features |
Firewall protection, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), fanless, web threat protection, 3G/4G USB Dongle Support, CAPWAP support, application filtering, FortiLink Mode |
| Encryption Algorithm |
SSL, TLS 1.3 |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Expansion / Connectivity |
|
| Interfaces |
3 x 1000Base-T – RJ-45 |
|
1 x FortiLink – RJ-45 |
|
1 x 1000Base-T – RJ-45 (WAN / DMZ) |
|
1 x console – RJ-45 |
|
1 x USB 3.0 – Type A |
| Miscellaneous |
|
| Compliant Standards |
UL, VCCI, C-Tick, cUL, CB, FCC Part 15 Class B |
| Power |
|
| Power Device |
External power adapter |
| Installed Qty |
1 |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
16.6 Watt |
| Software / System Requirements |
|
| OS Provided |
FortiOS |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
10 – 90% (non-condensing) |
