| Device Type |
Security appliance |
| Built-in Devices |
DSL modem |
| Width |
8.5 in |
| Depth |
7 in |
| Height |
2.4 in |
| Weight |
3.53 lbs |
| Processor / Memory / Storage |
|
| Processors Installed |
1 x Fortinet FortiASIC SOC4 |
| Networking |
|
| Form Factor |
Desktop / wall mountable |
| Connectivity Technology |
Wireless, wired |
| Framing Format |
ANSI T1.413 |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth LE, IEEE 802.11ax (Wi-Fi 6) |
| Network / Transport Protocol |
TCP/IP, UDP/IP, IPSec, HTTP, HTTPs, IPv4 |
| Remote Management Protocol |
HTTP, HTTPS |
| Frequency Band |
2.4 GHz, 5 GHz |
| Performance |
|
| IPS throughput (enterprise traffic mix) |
1 Gbps |
| NGFW throughput (enterprise traffic mix) |
800 Mbps |
| Threat protection throughput (enterprise traffic mix) |
600 Mbps |
| Firewall throughput (1518/512/64-byte UDP) |
5 Gbps |
| Firewall latency (64-byte UDP) |
2.97 µs |
| Firewall throughput |
7.5 Mpps |
| VPN throughput (512-bit IPSec) |
4.4 Gbps |
| VPN throughput (SSL) |
490 Mbps |
| SSL inspection throughput |
310 Mbps |
| Application control throughput |
990 Mbps |
| CAPWAP throughput |
3.5 Gbps |
| Maximum data rate (2.4 GHz) |
450 Mbps |
| Maximum data rate (5 GHz) |
1300 Mbps |
| Capacity |
|
| Concurrent TCP sessions |
700,000 |
| New TCP sessions per second |
35,000 |
| Firewall policies |
5000 |
| Gateway to gateway IPSec VPN Tunnels |
200 |
| Client to gateway IPSec VPN tunnels |
250 |
| Concurrent SSL VPN users |
200 |
| SSL inspection CPS |
320 |
| SSL inspection concurrent sessions |
55,000 |
| Virtual domains |
10 |
| Maximum virtual domains |
10 |
| Number of FortiSwitches |
8 |
| Number of FortiAP devices |
16 |
| Number of FortiAP devices (tunnel) |
8 |
| Number of FortiToken devices |
500 |
| Status Indicators |
|
| Power, status, WAN, SFP, HA, DSL, Wi-Fi, 3G/4G |
|
| Features |
|
| VPN support, Trusted Platform Module (TPM), 3G/4G USB Dongle Support, SSL inspection, 3×3 MIMO technology, SD-WAN support, GNSS Bias |
|
| Encryption Algorithm |
|
| SSL, 256-bit AES, 256-bit SHA, TLS 1.3 |
|
| Compliant Standards |
|
| IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
|
| Antenna |
|
| Antenna |
External detachable |
| Antenna Qty |
6 |
| Communications |
|
| Digital Signaling Protocol |
ADSL2, ADSL2+, VDSL2 |
| Mobile Broadband Access |
Yes |
| Generation |
3G, 4G |
| Cellular Protocol |
UMTS, HSPA+, LTE |
| Cellular Band |
UMTS/HSPA+ B1/B2/B4/B5/B6/B8/B9/B19 / LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B18/B19/B20/B26/B28/B29/B30/B32/B41/B42/B43/B46/B48/B66 |
| Protocols & Specifications |
|
| ITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite) |
|
| Expansion / Connectivity |
|
| Expansion Slots |
2 Nano SIM card |
| Interfaces |
2 x 1000Base-T/1000Base-X – RJ-45/SFP (mini-GBIC) (WAN) ¦ 6 x 1000Base-T – RJ-45 ¦ 2 x 1000Base-T (FortiLink) – RJ-45 ¦ 1 x DSL – RJ-11 ¦ 1 x USB 3.0 – Type A ¦ 1 x console – RJ-45 ¦ 6 x antenna – SMA |
| Miscellaneous |
|
| Cables Included |
1 x network cable ¦ 1 x RJ-11 cable |
| Compliant Standards |
|
| UL, VCCI, BSMI, cUL, CB, FCC, ICES, RCM, USGv6 |
|
| Power |
|
| Power Device |
External power adapter |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Power Redundancy |
Optional |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Power Consumption Operational |
28.07 Watt |
| Software / System Requirements |
|
| OS Provided |
FortiOS |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
20 – 90% (non-condensing) |
