Network Adapters
Fortinet Interface Module FIM-7920E – expansion module – 100 Gigabit QSFP28 x 4
Fortinet Interface Module FIM-7920E – Expansion module – 100 Gigabit QSFP28 x 4
AED418,899.00
The FIM-7920E interface module is a hot swappable module that provides data, management and session sync/heartbeat interfaces, base backplane switching and fabric backplane session-aware load balancing for a FortiGate-7000 series chassis. The FIM-7920E includes an integrated switch fabric and DP2 processors to load balance millions of data sessions over the chassis fabric backplane to FPM processor modules.
| General | |
|---|---|
| Device Type | Expansion module |
| Form Factor | Plug-in module |
| Networking | |
|---|---|
| Ports | 100 Gigabit QSFP28 x 4 |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet, 100 Gigabit Ethernet |
| Data Transfer Rate | 100 Gbps |
| Status Indicators | Power, status, alarm, HA |
| Features | Hot swap module replacement |
| Expansion / Connectivity | |
|---|---|
| Interfaces | 4 x 100Gb Ethernet – QSFP28, 2 x 10Gb Ethernet – SFP+, 4 x 1000Base-T (management) – RJ-45, 1 x USB 3.0 – 9 pin USB Type A |
| Dimensions & Weight | |
|---|---|
| Width | 11.3 in |
| Depth | 13.8 in |
| Height | 1.2 in |
| Weight | 7.12 lbs |
