FS605IS NETGEAR 5-PORT 10/100 SWITCH

Physical Specifications

• Dimensions:
  FS605: 147 x 96.7 x 28.5 mm (5.79 x 3.81 x 1.12 in)
  FS608: 171 x 113.2 x 28.5 mm (6.73 x 4.46 x 1.12 in)
• Weight:
  FS605: 0.192 kg (0.424 lb)
  FS608: 0.278 kg (0.614 lb)

Power Consumption:

• Maximum power consumption 7.5W DC operating voltage 7.5V at 1A input

Network Ports

• 5 auto-speed sensing 10/100 Mbps ports; Auto UplinkÂ? (MDI-MDIX) for connection to other hubs and switches without special cables

Standards Compliance

• IEEE 802.3i 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3x Flow Control
• Compatible with Microsoft® Windows®, Mac® OS, NetWare®, Linux®

LED Interfaces

• System power
• Link, speed and activity indicators for each port

Safety Agency Approvals for Power Adapter

• C-Tick, CE mark

Environmental Specifications

• Operating temperature: 0° to 40°C (32° to 104°F)
• Operating relative humidity: 10%-90% non-condensing

Emissions Compliance

• CE mark, commercial FCC Part 15 Class B, VCCI Class B, C-Tick, EN 55022, CISPR 22

Warranty

• NETGEAR 3-year Warranty

Package Contents

• 5- or 8-port 10/100 Mbps Fast Ethernet Switch (FS605v3 or FS608v3)
• AC power adapter
• Vertical stand
• Installation guide
• Warranty/support information card
