Gefen EXT-3G-HD-C 3G-SDI to HDMIConverter

Add to Wishlist

AED1,499.00

Add to Wishlist

The Gefen EXT-3G-HD-C converts audio and video from 3G-SDI to HDMI format, at resolutions up to 1080p. Audio formats up to 8 channels of LPCM are supported. This product is fully compatible with the Gefen Syner-G software suite for firmware updates and in-depth device configuration. The unit’s compact enclosure, while light enough to be held in place using double-sided touch fastener tape, features a standard 1/4″-20 attachment provision as well as a detachable surface-mounting bracket. This, along with a flexible power input circuitry capable of accepting a wide range of DC voltages and a locking power supply connector, makes the EXT-3G-HD-C useful for mobile A/V applications as well as fixed installations.

SKU: EXT-3G-HD-C Category: Tag:
Maximum Resolution
Input: 1080p60
Output: 1080p
10-bit support on input and output
Color Spaces Supported
HDMI YCbCr 4:4:4
DVI RGB 4:4:4
Up to 10-bit
Audio Support
LPCM up to 7.1 channels
Clock Speed
Max Pixel Clock: 150 MHz
Maz TMDS Clock: 225 MHz
I/O Connections
1 x SDI (BNC) female input
1 x Locking HDMI Type A female output
1 x USB mini-B
1 x 3-pin locking power connector
Dip Switches
5 x DIP configuration switches
LED Indicators
1 x Green LED
1 x Blue LED
Power Supply
12 VDC nominal (6 to 24 VDC operating range)
Power Consumption
2 W maximum
Operating Temperature
32 to 122°F / 0 to 50°C
Storage Temperature
-4 to 185°F / -20 to 85°C
Operating Humidity
5 to 90% RH (non-condensing)
Storage Humidity
0 to 95% RH (non-condensing)
Dimensions
2.9 x 1.2 x 2.3″ / 74 x 30 x 59 mm
Weight
0.3 lb / 150 g
Packaging Info
Package Weight
1.31 lb
Box Dimensions (LxWxH)
10.5 x 6.9 x 4″
