Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m – 1000 Mbps – TAA

Add to Wishlist

Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multi-Mode SC fiber



  • A cost-effective way to extend/bridge networks using fiber cabling
  • Advanced features include Link-loss forwarding, remote monitor status, and two frame lengths
  • Supports a maximum fiber cable length of 550m
  • Supports full or half-duplex operation
  • Quick and simple installation, easy to use

AED1,299.00

Add to Wishlist
The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).

A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis and a simple plug-and-play installation with minimal configuration required.

Applications

  • Provides network connectivity to users or network segments located in isolated areas of a large complex or a separate building
  • Suitable for environments such as government agencies, where security threats (network tapping, etc.) need to be prevented
  • Connect traffic control/monitoring systems at extreme distances to the main office
  • Extend network connectivity to remote areas of stadiums, auditoriums, or other venues
  • Converts 1000Base-SX fiber optic signals to 1000Base-T Ethernet over multimode fiber cable
SKU: ET91000SC2 Category: Tag:

Specifications Table

Category Details
Connector(s)
Local Unit Connectors – 1 × Fiber Optic SC Duplex
– 1 × RJ-45
Environmental
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -10°C to 70°C (14°F to 158°F)
Humidity 10% to 90% RH
Hardware
PoE No
WDM No
Packaging Information
Package Height 3.6 in [9.1 cm]
Package Length 8.1 in [20.6 cm]
Package Width 5.4 in [13.7 cm]
Shipping Weight 1.7 lb [0.8 kg]
Package Quantity 1
Performance
Max Data Transfer Rate 2000 Mbps (Full Duplex Mode)
Max Transfer Distance 550 m (1804 ft)
Type Multi Mode
Wavelength 850 nm
Fiber Operating Mode Half/Full-Duplex
Auto MDIX Yes
MTBF 65,000 Hours
Physical Characteristics
Weight of Product 13.9 oz [395 g]
Color Black
Material Steel
Product Dimensions (L × W × H) 5.9 in × 3.5 in × 1.0 in
(15 cm × 9 cm × 2.5 cm)
Power
Power Source AC Adapter Included
Input Voltage 100 – 240 AC
Input Current 0.36 A
Output Voltage 12V DC
Output Current 1.6 A
Center Tip Polarity Positive
Plug Type M
Power Consumption 4 Watts
What’s in the Box
Included Items – 1 × Fiber Media Converter
– 1 × Universal Power Adapter (Region-specific)
– 1 × Grounding Screw
– 1 × Instruction Manual
