HighPoint RocketRAID 4520SGL 8-Channel Internal SAS/SATA PCIe 2.0 Hardware RAID Controller

Add to Wishlist
Key Features
  • PCIe 2.0 x8 Host Interface
  • 8 x 6 Gb/s Internal SAS/SATA Channels
  • Hardware RAID 0, 1, 5, 6, 10, 50 & JBOD
  • 512MB DDR3 Cache Memory
  • DV Mode Technology
  • Supports Windows, macOS & Linux

AED1,999.00

Add to Wishlist

HighPoint 4520SSGL Overview

The RocketRAID 4520SGL 8-Channel Internal SAS/SATA PCIe 2.0 Hardware RAID Controller from HighPoint supports up to eight internal SAS or SATA 6 Gb/s physical links. Featuring an onboard processor and 512MB DDR3 cache memory, it is suitable for use with a wide array of servers and workstations. This low-profile host bus adapter uses a PCI-Express 2.0 x8 bus interface and supports RAID 0/1/5/6/10/50 and JBOD configurations.

8-Port, PCIe x8 2.0 6 Gb/s SAS/SATA Hardware RAID HBA
The RocketRAID 4520SGL’s dedicated RAID-on-Chip processor and 512 MB of onboard DDR3 cache memory offload RAID processing from the host system, ensuring stable and high-performance data transfers.
Reliable
HighPoint’s comprehensive suite of data security, RAID recovery, and storage maintenance features provide an enhanced level of reliability.
HighPoint DV Mode
HighPoint’s DV Mode technology features a caching algorithm designed for video production applications. DV Mode reorganizes I/O in order to minimize the latency time of write-back caching workflow. This innovative new technology maintains consistent, sustained high-performance data transfer, a key component of any storage system dedicated to post-production applications.
SKU: RR4520SGL Category:

HighPoint 4520SSGL Specs

General
System Connection PCI Express 2.0 x8
Internal I/O 2 x Mini SAS (SFF 8087) SAS-2 6 Gb/s
Cache Memory 512 MB DDR3 ECC
RAID RAID 0, 1, 10, 5, 50, 6, JBOD
OS Compatibility Windows 7 to 11
Windows Server 2008 to 2022
macOS 10.6 or Later
Linux
*As of January, 2023: Check with manufacturer for the most up-to-date compatibility
Environmental
Operating Temperature 41 to 131°F / 5 to 55°C
Operating Humidity 5 to 60%
Storage Temperature -4 to 176°F / -20 to 80°C
Physical
Form Factor Low-Profile
Audible Alarm Yes
Status Monitoring None
Certifications CE, FCC
*as per Manufacturer
Mean Time Between Failures (MTBF) 920.00 Million Hours
Dimensions 6.57 x 2.68 x 0.65″ / 166.88 x 68.07 x 16.51 mm
Weight 0.25 lb / 113 g
