04 3550600 052 7036860

HPE Aruba Networking CX 8100 40x10GBase-T 8x10G SFP+ 4×40/100G QSFP28 Switch – switch – 40 ports – managed –

Add to Wishlist

Quick tech specs

  • T 8x10G SFP+ 4×40/100G QSFP28 Switch
  • L3
  • 40 x 100/1000/2.5G/5G/10GBase- -T + 8 x Gigabit SFP / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28
  • rack-mountable
  • Switch
  • managed
  • back to front airflow

AED149,099.00

Add to Wishlist

Know your gear

The HPE Aruba Networking CX 8100 Switch offers a flexible and innovative approach to addressing the application, security and scalability demands of the mobile, cloud and IoT era. It serves the needs of the next-generation core and aggregation layer of campuses, as well as virtual and highly dynamic data center environments. This switch provides up to 1.76 Tbps of capacity, with line-rate Gigabit Ethernet interfaces including support for Smart Rate (1/2.5/5 Gb/s), 10 Gb/s, 25 Gb/s, 40 Gb/s and 100 Gb/s.

SKU: R9W93A#ABA Category: Tag:
Category Details
Overview
Brand Aruba
Product Line HPE Aruba Networking CX
Model 8100 40x10GBase-T 8x10G SFP+ 4×40/100G QSFP28
Manufacturer Aruba Data Center Switches
Processor
Clock Speed 1.8 GHz
Processor Brand ARM
Processor Number Cortex-A72
Processors Installed 1
Memory
Flash Memory Installed 32 GB
RAM Installed 16 GB
Network & Communication
Advanced Switching Layer 3
Compliant Standards IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3ba, IEEE 802.3by, IEEE 802.3x, IEEE 802.3z
Features Address Resolution Protocol, Aruba Virtual Switching Extension (VSX), BFD, BGP-4, BPDU, DCB, Dynamic VXLAN with BGP-EVPN, ECMP, ERPS, GRE, Layer 2 switching, Layer 3 routing, NTP, OSPF, Policy-based routing, Port mirroring, QoS, RPVST+, RoCE, RoCEv2, sFlow, UDLD
Form Factor Rack-mountable
Jumbo Frame Support 9000 bytes
MAC Address Table Size 147,456 entries
Manageable Yes
Ports 40
Product Type Switch
Remote Management MIB, SNMP, SNMP 2, SNMP 3
Routing Protocol BGP-4, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, RIP-2
Subcategory Network hubs and switches
Switching Type 10 Gigabit Ethernet
Expansion Slots
QSFP Slots 40 Gigabit QSFP+ / 100 Gigabit QSFP28
Connectivity
Interface Provided 1 x serial RJ-45, 1 x USB Type A AUX, 1 x USB-C console, 4 x 40/100Gbit LAN QSFP28/QSFP+, 4 x Gigabit/10Gbit LAN SFP+, 40 x 100/1000/2.5G/5G/10GBase-T RJ-45
Port Quantity 40
Port Type 100/1000/2.5G/5G/10GBase-T
Ports Type (2nd) Gigabit SFP / 10 Gigabit SFP+
Power
Frequency 50/60 Hz
Hot-Plug Hot-plug
Power Provided 550 watt
Power Supplies Installed 2
Power Supplies Supported 2
Required Voltage AC 100-127/200-240 volt
Technical Information
Humidity Range Storage 15 – 95% (non-condensing)
Max Operating Temperature 113°F
Max Storage Temperature 158°F
Min Operating Temperature 32°F
Min Storage Temperature -40°F
Operating Humidity 15 – 95% (non-condensing)
Operating System Required AOS-CX
Product Information
Airflow Direction Back to front airflow
Authentication Method RADIUS, SSH, SSH2, TACACS+
Capacity IGMP groups: 4000, IPv4 ACL entries (egress): 2048, IPv4 ACL entries (ingress): 16384, IPv4 routes (Multicast): 4096, IPv4 routes (Unicast): 24576, IPv6 ACL entries (egress): 512, IPv6 ACL entries (ingress): 4096, IPv6 routes (Multicast): 4096, IPv6 routes (Unicast): 12288, Link aggregation groups: 54, MAC ACL entries (egress): 2048, MAC ACL entries (ingress): 16384, Maximum number of VLANs: 1024, MLD groups: 4000, Packet buffer size: 32 MB
Country United States
Device Type Internal power supply
Localization English
Packaged Quantity 1
Performance Switching capacity: 1.76 Tbps
Ports (2nd) Quantity 8
Ports (3rd) Quantity 4
Included Items
Included Accessories 2-Post Rack Kit, 3 fan trays
Dimensions & Weight
Height 1.7 inch
Height (Rack Units) 1U
Weight 18.89 lbs
Width 17.4 inch
Depth 16 inch
Physical Characteristics
Color Category Black
Certifications & Listings
Compliant Standards AS/NZS CISPR 32:2015 Class A, CISPR 35, CISPR-32 Class A, CNS 13438 Class A, Directive 2014/35/EU, EMC 2014/30/EU, EN 55032:2015, EN 55035:2017, EN 60825-1:2014, EN 61000-3-2:2019, EN 61000-3-3:2013, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 62368-1:2014 Second Edition, EN 62368-1:2020 3rd Edition, EN 63000:2018, FCC CFR 47 Part 15:2018 Class A, ICES-003 Class A, IEC 60825-1:2014 Class 1, IEC 61000-3-2:2019, IEC 61000-3-3:2013, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 62368-1:2014, IEC 62368-1:2018, KN32 Class A, Laser Class 1, UL62368-1/CAN/CSA C22.2 No.62368-1, VCCI Class A
