HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI – switch – 52 ports – smart – rack-mountable

Add to Wishlist

Quick tech specs

  • Scalability and High Availability
  • Simplified Management
  • Comprehensive Security Control
  • Enhanced Quality of Service

AED47,799.00

Add to Wishlist

Know your gear

The HPE Aruba FlexNetwork 5140 EI Switch Series delivers scalability and enhances the reliability of the network with HPE Intelligent Resilient Fabric (IRF) technology. IRF stacking enables virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router.

The HPE FlexNetwork 5140 EI Switch Series supports flexible authentication methods including 802.1X and MAC Authentication for greater security and policy-driven application authentication. Per-user access control lists (ACLs) provide identity-driven security and access control.

SKU: JL824A#ABA Category: Tag:
Category Specification
Overview
Brand HPE
Product Line HPE FlexNetwork
Model 5140 48G PoE+ 4SFP+ EI
Manufacturer Aruba
Memory
Flash Memory Installed 256 megabyte
Memory Technology SDRAM
RAM Installed 512 megabyte
Network & Communication
Advanced Switching Layer 3
Compliant Standards ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1r, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features Access Control List (ACL) support, ARP support, Auto-uplink (auto MDI/MDI-X), BOOTP support, BPDU protection, Committed Access Rate (CAR), Device Link Detection Protocol (DLDP) support, DHCP protection, DHCP relay, DHCP server, DiffServ support, Dynamic ARP protection, Energy Efficient Ethernet, Ethernet OAM, Flow control, Full duplex mode, Generic Attribute Registration Protocol (GARP), Guest VLAN, Half duplex mode, High Availability, ICMP Router Discovery Protocol (IRDP), IGMP snooping, Intelligent Resilient Fabric Technology (IRF), IP source guard, Link Aggregation, Link Aggregation Control Protocol (LACP), LLDP-MED, Load balancing, MLD snooping, Multiple Registration Protocol (MRP), Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), OpenFlow support, Port isolation, Port Security, Proxy ARP, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, sFlow, Smart Link, Spanning Tree Protocol (STP) support, STP Root Guard, Strict Priority Queuing (SPQ), UDP support, Virtual Route Redundancy Protocol (VRRP) support, VLAN Double Tagging (Q-in-Q), VLAN support, Weighted Round Robin (WRR)
Form Factor (Hubs & Switches) Rack-mountable
Jumbo Frame Support 9216 bytes
MAC Address Table Size 16384 entries
Manageable Yes
PoE Budget 370 watt
Ports 52
Power Over Ethernet (PoE) PoE+
Product Type Switch
Remote Management CLI, HTTPS, ICMP, NTP, RADIUS, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP
Routing Protocol CIDR, IGMP, IGMPv3, OSPF, OSPFv2, OSPFv3, RIP-1, RIP-2, Static IPv4 routing, Static IPv6 routing
Smart Yes
Status Indicators Port status, System
Subcategory Network hubs and switches
Switching Type Gigabit Ethernet
Connectivity
Interface Provided 1 x console RJ-45 management, 1 x micro-USB 5 pin USB header management, 4 x Gigabit / 10Gbit LAN SFP+, 48 x 1000Base-T RJ-45 PoE+
Port Quantity 48
Port Type 10/100/1000 (PoE+)
Ports Type (2nd) 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+
Power
Frequency 50/60 hertz
Power Provided 478 watt
Required Voltage AC 100-240 volt
Technical Information
Encryption SSL
Humidity Range Storage 5 – 95% (non-condensing)
Max Operating Temperature 113 degree Fahrenheit
Max Storage Temperature 158 degree Fahrenheit
Min Operating Temperature 23 degree Fahrenheit
Min Storage Temperature -40 degree Fahrenheit
Operating Humidity 10 – 90% (non-condensing)
Product Information
Authentication Method HWTACACS, RADIUS, Secure Shell v.2 (SSH2), TACACS+
Capacity IPv4 routing table entries: 512, IPv6 routing table entries: 256, VLAN IDs: 4094
Country United States
Device Type Internal power supply
Localization English
Packaged Quantity 1
Performance Latency (10 Gbps): 3 µs, Latency (1000 Mbps): 5 µs, Routing/switching capacity: 176 Gbps, Throughput: 132 Mpps
Ports (2nd) Quantity 4
Rack Mounting Kit Included
Dimensions & Weight
Height 1.7 inch
Height (Rack Units) 1
Weight 17.64 lbs
Width 17.3 inch
Depth 14.2 inch
Physical Characteristics
Color Category Black
Certifications & Listings
Compliant Standards AS/NZS CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 24, EN 300 386, EN 55032, EN 60825-1, EN 60825-2, EN 61000-3-2, EN 61000-3-3, EN 62368-1:2014/A11:2017, EN55024, ETSI EN 300 386, FCC Part 15 B Class A, FDA 21 CFR, GB/T9254, ICES-003 Class A, IEC 60950-1, IEC 62368-1, IPv6 Ready, Plug and Play, RoHS, UL 60950-1, VCCI-CISPR 32:2016 Class A, WEEE, YD/T993
ENERGY STAR Certified No
EPEAT Compliant No
TCO Certified No
