HPE JZ182A – Aruba AP377 Access Point


Aruba AP-377 (RW) Outdoor 11ac AP

13,099.00 د.إ

JZ182A Overview

Weatherproof and temperature hardened, the Aruba 370 Series Access Points deliver 802.11ac Wave 2 specifically designed for outdoor and environmentally challenging locations.

Quick Specs

Figure 1 shows the appearance ofĀ JZ182A.
JZ182A

Table 1 shows the Quick Specs.

Product Code JZ182A
Data Transfer Rate 1733 Mbps
Frequency Band 2.4 GHz, 5 GHz
Performance Maximum data rate (2.4 GHz): 300 Mbps | Maximum data rate (5 GHz): 1.733 Gpps
Capacity Wireless clients per Wi-Fi radio: 256 | BSSIDs per radio: 16
Antenna Internal
Power Consumption Operational 23 Watt
Interfaces 1 x 1000Base-X – SFP (mini-GBIC) | 1 x 1000Base-T – RJ-45 | 1 x micro-USB

Product Details

Figure 2 shows the front panel ofĀ JZ182A.
JZ182A front

Figure 3 shows the back panel ofĀ JZ182A.
JZ182A back

JZ182AĀ provides these features:

Outdoor Weatherproof and Temperature-hardened 802.11ac Wave 2 Access Point

  • The Aruba 370 Series Access Points are ruggedized for deployment in harsh indoor environments or within an enclosure for exposed environments.
  • These access points provide outdoor-appropriate 802.11ac Wave 2 access.

Flexible Network Connectivity Options

  • The Aruba 370 Series Access Points enable flexible network connectivity options with dual Gigabit Ethernet uplink options.
  • One of the uplink ports supports 1000BASE-T Ethernet connections (RJ-45) for power and connectivity.
  • One of the uplink ports supports 1000BASE-X Ethernet connections (SFP) allowing the use of optical connections for longer reach.

Includes Support for 802.11ac Wave 2 with 4×4:4SS, 160MHz, and MU-MIMO

  • The Aruba 370 Series Access Points support 802.11ac with Wave 2 features including 4×4:4SS, 160 MHz channel width and Multi-User MIMO transmission.
  • Supports maximum simultaneous data rates of 2.0 Gbps with 1733 Mbps in the 5 GHz band and 300 Mbps in the 2.4 GHz band.

Integrated BLE Beacon for Location Services

  • The Aruba 370 Series Access Points have an integrated Bluetooth Low Energy (BLE) beacon to enable Aruba location services such as beacon management, location notifications and navigation.
  • The integration of a BLE beacon enables businesses to leverage mobile context to develop applications that deliver an enhanced user experience and increase the value of the network infrastructure.

The Accessories

TableĀ 2Ā showsĀ theĀ accessories ofĀ JZ182A.

Mount Kit
JW052A AP-270-MNT-V1 270 Series Mt Kit
Power Adaptor
JW629A PD-9001GR-AC 30W 802.3at PoE+ 10/100/1000 Ethernet Indoor Rated Midspan Injector

Compare to Similar Items

Table 3 shows the comparison ofĀ JZ182A.

Module JZ182A JZ162A
Data Transfer Rate 1733 Mbps 1733 Mbps
Frequency Band 2.4 GHz, 5 GHz 2.4 GHz, 5 GHz
Performance Maximum data rate (2.4 GHz): 300 Mbps | Maximum data rate (5 GHz): 1.733 Gpps Maximum data rate (2.4 GHz): 300 Mbps | Maximum data rate (5 GHz): 1.733 Gpps
Capacity Wireless clients per Wi-Fi radio: 256 | BSSIDs per radio: 16 Wireless clients per Wi-Fi radio: 256 | BSSIDs per radio: 16
Antenna Internal External detachable
Power Consumption Operational 23 Watt 23 Watt
Interfaces 1 x 1000Base-X – SFP (mini-GBIC) | 1 x 1000Base-T – RJ-45 | 1 x micro-USB 1 x 1000Base-X – SFP (mini-GBIC) | 1 x 1000Base-T – RJ-45 | 1 x micro-USB
SKU: JZ182A Category: Tag:

JZ182A Specification



JZ182A Specification

General
Device Type Wireless access point
Ruggedized Design Outdoor
Width 9.1 in
Depth 8.7 in
Height 5.1 in
Networking
Form Factor External
Connectivity Technology Wireless
Data Transfer Rate 1733 Mbps
Line Coding Format CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM
Data Link Protocol IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Spread Spectrum Method OFDM, DSSS
Frequency Band 2.4 GHz, 5 GHz
Performance Maximum data rate (2.4 GHz): 300 Mbps | Maximum data rate (5 GHz): 1.733 Gpps
Capacity Wireless clients per Wi-Fi radio: 256 | BSSIDs per radio: 16
Status Indicators System, status
Compliant Standards IEEE 802.3at, IEEE 802.3az
Antenna
Antenna Internal
Antenna Qty 6
Internet of Things (IoT)
Communications Technology Bluetooth Low Energy (LE)
Expansion / Connectivity
Interfaces 1 x 1000Base-X – SFP (mini-GBIC) | 1 x 1000Base-T – RJ-45 | 1 x micro-USB
Miscellaneous
Compliant Standards CB, UL 2043, FCC, cTUVus, IP67, IP68, EN 60601-1-1, LVD 2014/35/EU, Directive 2014/30/EU, ISED, Directive 2014/53/EU, IEC/EN/UL 60950, EN60601-1-2
Power
Power Over Ethernet (PoE) Supported PoE+
Power Consumption Operational 23 Watt
Software / System Requirements
OS Required ArubaOS, InstantOS
Environmental Parameters
Min Operating Temperature -40 °F
Max Operating Temperature 149 °F
Humidity Range Operating 5 – 95% (non-condensing)
