AirEngine AP7060DN Access Point Powered by unique Huawei 5G technologies, AirEngine AP7060DN is a cutting-edge Wi-Fi 6 (802.11ax) wireless Access Point (AP) that delivers ultra-low latency and a device rate of up to 6 Gbit/s ā ideal for handling high-bandwidth services, such as Virtual Reality (VR) and Augmented Reality (AR) interactive teaching, 4K and 8K High Definition (HD) video streaming, multimedia streaming, and desktop cloud. With omnidirectional antennas and 5G roaming technology, lossless roaming is also achieved, ensuring operational efficiency and a seamless user experience. In addition ā built for the intelligent era ā AirEngine AP7060DN facilitates the use of Internet of Things (IoT) applications, with a 10 GE uplink interface eliminating bottlenecks in upstream bandwidth. Winner of the “Best of Show Award” at Interop Tokyo 2019 and rated as the fastest Wi-Fi 6 AP (as of October, 2019) by the Tolly Group, a leading global Information Technology (IT) testing service, the AirEngine AP7060DN is applicable to a wide range of scenarios, including offices and education institutions. Wi-Fi 6 Technology Featuring Multi-User Multiple-Input Multiple-Output (MU-MIMO) and Orthogonal Frequency Division Multiple Access (OFDMA) for efficient data transmission, plus 1024 Quadrature Amplitude Modulation (QAM), 12 spatial streams, and an air interface rate of up to 6 Gbit/s. IoT Convergence Supports multiple IoT protocols such as Radio Frequency Identification (RFID) and ZigBee through IoT cards ā improving connectivity and enabling seamless upgrades for wireless enterprise systems. Cloud Management Supports cloud management, where customers can manage, operate, and maintain APs and services on Huaweiās cloud management platform, reducing network Operations and Maintenance (O&M) costs.
Network Accessories, Networking
Huawei AirEngine AP7060DN 6000 Mbit/s White Power over Ethernet (PoE)
2.4G, 5G, DC, PoE, Bluetooth, White
AED3,299.00
Feature | Specification |
---|---|
2.4 GHz | Y |
5 GHz | Y |
Maximum data transfer rate | 6000 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 1150 Mbit/s |
Maximum data transfer rate (5 GHz) | 4800 Mbit/s |
Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Number of users | 512 user(s) |
Bluetooth | Y |
Bluetooth version | 5.0 |
Full duplex | Y |
Tunnel forwarding | Y |
Auto MDI/MDI-X | Y |
MIMO | Y |
MIMO type | Multi User MIMO |
Wi-Fi Multimedia (WMM)/(WME) | Y |
STA isolation (same VLAN) | Y |
Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
MAC address filtering | Y |
System status alarm | Y |
DHCP snooping | Y |
Wireless Intrusion Detection System (WIDS) | Y |
Remote Authentication Dial-In User Service (RADIUS) | Y |
Dynamic ARP inspection (DAI) | Y |
IP Source Guard (IPSG) | Y |
Access Control List (ACL) | Y |
Blacklist | Y |
Whitelist | Y |
DHCP client | Y |
Web-based management | Y |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 1 |
DC-in jack | Y |
Power over Ethernet (PoE) | Y |
Placement | Ceiling |
Product colour | White |
International Protection (IP) code | IP41 |
Antenna type | Internal |
Operating relative humidity (H-H) | 5 – 95% |
Operating temperature (T-T) | -10 – 50 °C |
Storage temperature (T-T) | -40 – 70 °C |
Operating altitude | -60 – 5000 m |
Width | 220 mm |
Depth | 220 mm |
Height | 57 mm |
Weight | 1.8 kg |
Number of products included | 1 pc(s) |
