| Video |
| Image Sensor |
1/2.8″ CMOS |
| Max. Resolution |
1920 x 1080 |
| Scanning Mode |
Progressive Scan |
| Lens Type |
Fixed-focal |
| Focal Length |
2.8mm |
| Aperture |
F1.6 |
| Iris Control |
Fixed Iris |
| Angular Field of View |
105.8Āŗ(H),56.4Āŗ(V),121.2Āŗ(D) |
| Min. Illumination |
COLOR : 0.1 lux @ F1.6
B/W : 0 lux (IR LED ON) |
| Dynamic Range |
120dB (True WDR) |
| Electronic Shutter Speed |
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Day and Night |
Yes (ICR) |
| IR Distance (LEDs) |
30 m / 98.4 ft (4 ea) |
| Image Setting |
Exposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control) |
| Backlight Compensation |
– |
| Mirroring / Pivot |
Horizontal / Vertical / Pivot |
| Image Stabilizer |
– |
| De-fog |
Yes |
| Privacy Masking |
8 Zones |
| Intelligent Video |
Object Metadata: Human, Vehicle, Face
IDLA: Object Detection, Intrusion, Loitering, Line Crossing, Face Detection
ETC: Video Motion Detection, Active Tampering Alarm |
| Video Out |
– |
