Video |
Image Sensor |
1/2″ CMOS |
Max. Resolution |
1920 x 1080 |
Scanning Mode |
Progressive Scan |
Lens Type |
Vari-focal |
Focal Length |
12 ~ 50mm |
Aperture |
F1.5 ~ F1.9 |
Iris Control |
P-Iris |
Angular Field of View |
Wide : 33Āŗ(H), 18Āŗ(V), 38Āŗ(D)
Tele : 9Āŗ(H), 5Āŗ(V), 10Āŗ(D) |
Min. Illumination |
Color Mode : 0.02 lux @F1.5
BW Mode : 0 lux (IR LED ON) |
Dynamic Range |
120dB (True WDR) |
Electronic Shutter Speed |
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
Day and Night |
Yes (ICR) |
IR Distance (LEDs) |
20m (License plate capture up to 80km/h)
100m (Surveillance) |
Image Setting |
Configurable Exposure, White Balance, Sharpness |
Backlight Compensation |
– |
Mirroring / Pivot |
Horizontal / Vertical / Pivot |
Image Stabilizer |
– |
De-fog |
– |
Privacy Masking |
8 Zones |
Intelligent Video |
Video Motion Detection, Active Tampering Alarm, Trip Zone |
Video Out |
– |
Network |
Video Compression |
H.265, H.264 (MP), M-JPEG |
Intelligent Codec |
Yes |
Bitrate Control |
H.264 – CBR / VBR, H.265 – CBR / VBR |
Audio Compression |
ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law |
Two-way Audio |
Yes |
IP Camera Protocol |
DirectIP 2.0, ONVIF |
Max. Frame Rate |
25ips : 1920 x 1080
30ips : 1920 x 1080 |
Supported Resolution |
1920×1080, 1280×720, 704×480, 640×360, 352×240 |
Multi-video Streaming |
Quadruple Streaming |
Network Protocols |
DirectIP 2.0 Protocol, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,
RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, Upnp |
Security |
SSL Encryption, Multi-user Authority, IEEE 802.1x, IP Filtering, HTTPS, SSL Encryption |
Ethernet |
RJ45 (10/100BASE-T) |
Recording Session Buffer (NLTSrec) |
Yes (Up to 60MB) |
Edge Storage |
micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
Alarm and Event |
Trigger Event |
Motion Detection, Alarm in, Audio detection, Tampering, Trip Zone |
Event Notification |
Remote S/W, Email (with Image) |
Audio Alarm |
Yes |
Audio In / Out |
1 / 1 |
Alarm In / Out |
2 / 1 |
Environmental |
Vandal Proof Casing |
– |
Outdoor Ready |
IP66 |
Operating Temperature |
-40°C ~ +60°C (-40°F ~ +140°F) |
Operating Humidity |
0% ~ 90% |
Electrical |
Power Source |
100V ~ 240VAC |
Power Consumption |
100-240V~, 50/60Hz, 1.0-0.5A, 50W |
Approval |
FCC, CE, KC |
Mechanical |
Dimensions |
166.5mm x 129.5mm x 540mm (6.56″ x 5.1″ x 21.26″) |
Weight |
4.65 kg (10.25 lb) |
