| General |
|
| Device Type |
Security appliance |
| Height (Rack Units) |
1U |
| Width |
17.4 in |
| Depth |
20.5 in |
| Height |
1.7 in |
| Weight |
14.99 lbs |
| Processor / Memory / Storage |
|
| RAM |
4 GB |
| Hard Drive |
SSD 100 GB |
| Networking |
|
| Form Factor |
Rack-mountable |
| Airflow Direction |
Front to back airflow |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Network / Transport Protocol |
RSVP, IPSec, PPPoE, DHCP, DNS, DDNS |
| Routing Protocol |
OSPF, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, DVMRP, VRRP, PIM-SM, static IP routing, PIM-DM, OSPFv3, PIM-SSM, MSDP, ECMP, MPLS |
| Remote Management Protocol |
SNMP, Telnet, HTTP, SSH, CLI |
| Performance |
|
| Throughput (64-byte packet size) |
1700 Kpps |
| Routing (IMIX) |
5 Gbps |
| Routing throughput (1518-byte packet size) |
10 Gbps |
| Firewall throughput (IMIX) |
4 Gbps |
| VPN throughput (IMIX IPSec) |
1 Gbps |
| VPN throughput (1400 B IPSec) |
3.5 Gbps |
| Connection rate |
50000 connections per second |
| Application control (AVC) throughput |
6 Gbps |
| NGFW throughput |
1 Gbps |
| IPS throughput |
2 Gbps |
| Capacity |
|
| IPv4 routing table entries |
1000000 |
| IPv6 routing table entries |
600000 |
| Concurrent sessions |
380000 |
| Security policies |
4000 |
| Maximum number of NAT rules |
3000 |
| MAC addresses |
16000 |
| IPSec VPN tunnels |
2048 |
| GRE tunnels |
2048 |
| Security zones |
128 |
| Virtual routers |
128 |
| Virtual interfaces (VLANs) |
3000 |
| AppID sessions |
64000 |
| IPS sessions |
64000 |
| URLF sessions |
64000 |
| Features |
|
| Firewall protection |
Yes |
| NAT support |
Yes |
| VPN support |
Yes |
| PAT support |
Yes |
| IPv6 support |
Yes |
| Intrusion Prevention System (IPS) |
Yes |
| URL filtering |
Yes |
| DDos attack prevention |
Yes |
| Weighted Random Early Detection (WRED) |
Yes |
| Spanning Tree Protocol (STP) support |
Yes |
| Rapid Spanning Tree Protocol (RSTP) support |
Yes |
| Anti-spam protection |
Yes |
| Quality of Service (QoS) |
Yes |
| Dead Peer Detection (DPD) |
Yes |
| IPSec NAT-Traversal (NAT-T) |
Yes |
| DHCP server |
Yes |
| IPv4 support |
Yes |
| LLDP support |
Yes |
| DHCP relay |
Yes |
| DHCP client |
Yes |
| J-Flow |
Yes |
| Inspect SSL Encrypted Traffic |
Yes |
| Generic Routing Encapsulation (GRE) |
Yes |
| DiffServ Code Point (DSCP) support |
Yes |
| MACsec support |
Yes |
| Anti-virus protection |
Yes |
| Virtual Private LAN Service (VPLS) |
Yes |
| Label Distribution Protocol (LDP) |
Yes |
| Point-to-Point Protocol (PPP) |
Yes |
| High-Level Data Link Control (HDLC) |
Yes |
| Multilink Point-to-Point Protocol (MLPPP) |
Yes |
| Multilink Frame Relay (MLFR) |
Yes |
| Encryption Algorithm |
DES, Triple DES, MD5, IKE, SSL, SHA-1, PKI, 256-bit AES, IKEv2, 256-bit SHA |
| Authentication Method |
Secure Shell (SSH), X.509 certificates |
| Compliant Standards |
IEEE 802.1p, IEEE 802.1x |
| Expansion / Connectivity |
|
| Expansion Slots |
4 (total) / 4 (free) x expansion slot |
| Interfaces |
16 x 1000Base-T – RJ-45, 4 x 10GBase-X – SFP+, 1 x console – RJ-45, 1 x mini-USB, 1 x USB 2.0 – Type A, 1 x management – RJ-45 |
| Miscellaneous |
|
| Included Accessories |
Rack mount kit |
| MTBF |
28.1 years |
| Compliant Standards |
FCC Class A certified, RoHS2 |
| Power |
|
| Power Device |
Internal power supply – hot-plug |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Power Redundancy |
Optional |
| Power Consumption Operational |
150 Watt |
| Software / System Requirements |
|
| OS Provided |
JUNOS |
| Software Included |
Junos Software Base |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
10 – 90% (non-condensing) |
