Juniper QFX5110-48S-AFI2 Switches

Add to Wishlist
Model: Juniper QFX5110-48S-AFI2 Switches
Detail:
48 SFP+ and 4 QSFP28, back to front air flow, AC

AED49,999.00

Add to Wishlist

48 SFP+ and 4 QSFP28, back to front air flow, AC

QFX5110 access and aggregation switches deliver low latency, rich Layer 2 and Layer 3 features, VXLAN overlay deployments, and 100GbE uplinks, making it the industryā€™s most nimble line of switches.

Featuring L3 gateway capabilities for bridging between virtualized and bare-metal servers, the QFX5110 is designed for extremely agile data centers that demand support for overlay/underlay network architectures. The high-density 10GbE, 40GbE, and 100GbE ports also make the QFX5110 ideally suited for use in data center spine and leaf topologies and campus distribution.

The QFX5110 switches feature the following highlights:
Support high-density, multi-speed configurations for 10/40/100GbE access and aggregation, with up to 64 or 96 10GbE ports, up to four 100GbE uplink ports, and up to 32 40GbE ports in a 1 U platform
Deliver up to 2.56 Tbps Layer 2 and Layer 3 performance, with latency as low as 550 nanoseconds
Include a 1.8 GHz quad-core Intel CPU with 16 GB memory and 64 GB SSD storage
Feature rich automation capabilities with support for Python and zero touch provisioning (ZTP)
Support virtualization protocols such as Virtual Extensible LAN (VXLAN) and Open vSwitch Database (OVSDB) protocol as L2 Gateway or L3 Gateway
Offer advanced Junos OS features such as BGP add-path, MPLS, L3 VPN, and IPv6 6PE

Quick Spec

Table 1 shows the quick spec.

Product Code QFX5110-48S-AFI2
DimensionsĀ (W x H x D) 1.72 x17.36 x 20.48 inĀ (4.37 x 44.09 x 52.02 cm)
Rack units 1 U
Weight 23 lb (10.43 kg)
Operating system Junos OS
CPU 1.8 GHz quad-core Intel CPU
Power *Ā AFO/AFI: Max load: 300 W, Typical load: 195 W, Idle load: 150 W

*Ā Dual redundant (1+1) and hot-pluggable power supplies

*Ā 110-240 V single phase AC power

*Ā -36 to -72 V DC power
Cooling *Ā Redundant (N+1) and hot-pluggable fan modules for front-to- back and back-to-front airflow

*Ā Redundant variable-speed fans to reduce power draw
Total packet buffer 16 MB
Warranty Juniper standard one-year warranty
System Throughput Up to 1.76 Tbps (bidirectional)
Forwarding Capacity 1.32 Bpps
SKU: Juniper QFX5110-48S-AFI2 Category: Tags: ,

QFX5110-48S-AFI2Ā Specification
DimensionsĀ (W x H x D) 1.72 x17.36 x 20.48 inĀ (4.37 x 44.09 x 52.02 cm)
Rack units 1 U
Weight 23 lb (10.43 kg)
Operating system Junos OS
CPU 1.8 GHz quad-core Intel CPU
Power *Ā AFO/AFI: Max load: 300 W, Typical load: 195 W, Idle load: 150 W

*Ā Dual redundant (1+1) and hot-pluggable power supplies

*Ā 110-240 V single phase AC power

*Ā -36 to -72 V DC power
Cooling *Ā Redundant (N+1) and hot-pluggable fan modules for front-to- back and back-to-front airflow

*Ā Redundant variable-speed fans to reduce power draw
Total packet buffer 16 MB
Warranty Juniper standard one-year warranty
System Throughput Up to 1.76 Tbps (bidirectional)
Forwarding Capacity 1.32 Bpps
Interface Options

Ā

 *Ā 1GbE SFP: 48 (24 copper 1GbE)

*Ā 10GbE SFP+: 48/64 (with breakout cable)

*Ā 40GbE QSFP+: 4

*Ā 100GbE QSFP28: 4
Other Interface Notes

Ā

 *Ā Each QSFP+ port can be configured as a 4 x 10GbE interface or as a 40 Gbps port

*Ā Each QSFP28 port can be configured as a 4 x 10GbE interface a 40 Gbps port or as a 100 Gbps port

*Ā 1 USB 2.0 port

*Ā 1 RS-232 console port

*Ā 2 management ports: 2x SFP fiber ports or 1x RJ-45 and 1x copper SFP ports

*Ā Supported transceiver and direct attach cable

*Ā SFP+ 10GbE optical modules

*Ā SFP+ DAC cables: 1/3/5 m twinax copper and 1/3/5/7/10 m active twinax copper

*Ā SFP GbE optical and copper module

*Ā QSFP+ DAC cables: 1/3/5 m twinax copper and 7/10 m active twinax copper

*Ā QSFP+ AOC cables: 1/3/5/7/10/15/20/30 m cable

*Ā QSFP+ Optics: SR4, LX4, ESR4, IR, LR4

*Ā QSFP+ to SFP+ 10GbE direct attach breakout copper (1/3/10 m twinax copper and 5/7 m active twinax copper cable)

*Ā QSFP28 Optics: SR4, CWDM4, LR4

*Ā QSFP28 AOC: 10 m cable
MAC addresses per system 288,000
VLAN IDs 4,093
Number of link aggregation groups (LAGs) 104
Number of ports per LAG 32
Firewall filters (ingress / egress) 6,142 / 1,022
IPv4 unicast routes 128,000 prefixes; 208,000 host routes; 64 ECMP paths
IPv4 multicast routes 104,000
IPv6 unicast routes 84,000
IPv6 multicast routes 52,000
ARP entries 48,000
Jumbo frame 9,216 bytes
Spanning Tree Protocol (STP) *Ā Multiple Spanning Tree Protocol (MSTP) Instances: 64

*Ā VLAN Spanning Tree Protocol (VSTP) Instances: 253
Traffic mirroring *Ā Mirroring destination ports per switch: 4

*Ā Maximum number of mirroring sessions: 4

*Ā Mirroring destination VLANs per switch: 4
Operating temperature 32Ā° to 104Ā° F (0Ā° to 40Ā° C)
Storage temperature -40Ā° to 158Ā° F (-40Ā° to 70Ā° C)
Operating altitude Up to 2,000 ft (610 m)
Relative humidity operating Operating: 5% to 90% (noncondensing)
Relative humidity non-operating Non-operating: 0% to 95% (noncondensing)
