JVC SDI to Full NDI Converter

Add to Wishlist
Key Features
  • Plug-and-Play SDI-to-NDI Converter
  • SDI Input & Loop Output, Zero Latency
  • Up to 2048 x 1080p60 Video Resolution
  • Full NDI with up to 100 Mb/s Bitrate
  • Gigabit Ethernet with PoE Support
  • 8-Pin Mini-DIN PTZ Controller Support
  • Status LEDs & Tally Support
  • SD Card Slot for Firmware Updates
  • 1/4″-20 Mounting Thread

2,599.00 د.إ

Add to Wishlist

Encode SDI video output from a JVC camera to high-bitrate NDI format with this compact SDI to Full NDI Converter from JVC. The plug-and-play converter features an SDI input, an SDI loop output for local monitoring, and an RJ45 Ethernet port that supports full-NDI video output and PoE (Power-over-Ethernet).

The full-NDI support allows you to output high-resolution, zero-latency video up to 2048 x 1080p60 with high bitrate up to 100 Mb/s to preserve image quality. The unit also features LED status lights and an 8-pin mini-DIN to allow tally and PTZ control pass-through from a unit such as the JVC RM-LP100 PTZ controller. The converter is powered using either PoE or with the USB Type-B input, which can also be used for data transfer. An SD card slot is used for firmware updates, and the 1/4″-20 thread can be used to mount the converter onto a console or rig.

Key Features
Plug-and-play SDI-to-NDI converter
Preserves image quality with up to 100 Mb/s high bitrate
One SDI input, one SDI loop output, one NDI/RJ45 Gigabit Ethernet port
8-pin mini-DIN connector for PTZ control pass-through for controllers such as the JVC RM-LP100 PTZ controller
Supports video resolutions up to 2048 x 1080p60
USB 2.0 Type-B connector for power input and data transfer
SD card slot for firmware updates
Zero latency with full NDI
Power-over-Ethernet (PoE) support via Ethernet
LED status indicators and tally support
1/4″-20 mounting thread
SKU: PROCONVERTSDI Category: Tag:
Inputs / Outputs
Video Inputs
1x BNC (3G-SDI) Female
Audio Inputs
No
Video Outputs
1x BNC (3G-SDI) Female (Loop Output)
1x RJ45 (NDI)
Audio Outputs
No
Other I/O
1x RJ45 LAN, NDI, PoE Input/Output
1x USB-B Input (Shared Power & Data Transfer)
1x Mini-DIN 8-Pin PTZ Input/Output
Expansion Slots
No
Latency
SDI Input/Output: to 0 ms
Format Support
Input Video Format
SDI
DCI 2K at 60 fps
Output Video Format
RJ45 / SDI
DCI 2K at 60 fps
Standards
HDR Support
Not Specified by Manufacturer
IP Streaming
Video IP Encoding
NDI: 2048 x 1080 at 60p (100 Mb/s)
Hardware
Tally Light
Yes
Media Card Reader
1x SD (Unspecified Type)
Wireless
No
Power
Power I/O
1x USB-B (5 VDC ) Input
PoE Support
PoE 802.3af
Power Consumption
Device: 5 VDC
General
Rack Form Factor
No
Packaging Info
Package Weight
1.65 lb
Box Dimensions (LxWxH)
8.6 x 7.7 x 1.6″
