Kingston KSM24RS4-16HAI / KSM24RS4/16HAI 16GB DDR4 PC4-2400MHz ECC Registered RAM

Kingston KSM24RS4-16HAI / KSM24RS4/16HAI 16GB DDR4 PC4-2400MHz ECC Registered w/Parity 288-Pin DIMM – Brand New

Kingston KSM24RS4-16HAI / KSM24RS4/16HAI 16GB DDR4 PC4-2400MHz ECC Registered w/Parity 288-Pin DIMM – Brand New

Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:

• Power Supply: VDD=1.2V • VDDQ = 1.2V

• VPP – 2.5V • VDDSPD=2.25V to 2.75V

• Functionality and operations comply with the DDR4 SDRAM datasheet

• 16 internal banks • Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for the banks in the same or different bank group accesses are available

• Data transfer rates: PC4-2400, PC4-2133, PC4-1866, PC4-1600

• Bi-Directional Differential Data Strobe

• 8 bit pre-fetch

• Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)

• Supports ECC error correction and detection

• On-Die Termination (ODT)

• Temperature sensor with integrated SPD

• This product is in compliance with the RoHS directive.

• Per DRAM Addressability is supported

• Internal Vref DQ level generation is available

• Write CRC is supported at all speed grades

• CA parity (Command/Address Parity) mode is supported
