DTāIN4āF32 is a fourāchannel 4K@60Hz (4:2:0), long reach, HDBaseT input card for the VSā3232 Series Modular MultiāFormat Digital Matrix Switchers. DTāIN4āF32 inputs four long reach HDBaseT signals with bidirectional RSā232 and IR from the line to the chassis.
Network Adapters
Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card – expansion module – HDBaseT x 4 + RS-232 x 4 + IrDA x 4
Kramer DT-IN4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Input Card – Expansion module – HDBaseT x 4 + RS-232 x 4 + IrDA x 4
AED8,199.00
General |
---|
Device Type | Expansion module |
Form Factor | Plug-in module |
Networking |
Ports | HDBaseT x 4 + RS-232 x 4 + IrDA x 4 |
Connectivity Technology | Wired |
Data Link Protocol | HDBaseT |
Performance | Maximum data rate: 10.2 Gbps |
Maximum data rate (per graphic channel): 3.4 Gbps |
Features | HDTV Compatible, HDCP compliant, 4K resolution support, 3D Pass-Through, Kramer Equalization & re-Klocking Technology, 12-bit Deep Color support, bi-directional IR, HDBaseT Long Reach Mode, bidirectional RS-232 |
Compliant Standards | HDCP 1.4 |
Expansion / Connectivity | Interfaces: 4 x HDBaseT – RJ-45 – female |
4 x RS-232 – terminal block |
4 x IrDA – terminal block |
Miscellaneous | Included Accessories: Screwdriver |
Compliant Standards | RoHS, WEEE |
Power | Power Consumption Operational: 10 Watt |
Dimensions & Weight | Width: 8.5 in |
Depth: 7.5 in |
Height: 0.8 in |
Weight: 10.58 oz |
Dimensions & Weight (Shipping) | Shipping Width: 9.8 in |
Shipping Depth: 8.9 in |
Shipping Height: 2.2 in |
Shipping Weight: 17.64 oz |
Environmental Parameters | Min Operating Temperature: 32 °F |
Max Operating Temperature: 104 °F |
Humidity Range Operating: 10 – 90% (non-condensing) |
