Kramer VP-778 8-Input Presentation Matrix Switcher/Scaler with Seamless Video Cuts & 4K30 Output Support

Add to Wishlist
  • Pix Perfectā„¢ Scaling – State-of-the-art Kramer technology.
  • K-IIT XLā„¢ Picture-in-Picture Image Insertion Technology – Ultra-stable picture-in-picture, picture-and-picture and split-screen.
  • Seamless Video Switching – Swap or follow (transition type) and cut or fade (transition effect).
  • Dual Scalers – “Live” seamless transitions with two independent outputs.
  • 8 Input Buttons per Channel.

د.إ30,899.00

Add to Wishlist

Dual independent scalers with seamless switching

The Kramer VP-778 is a presentation matrix switcher/scaler that can be configured as a single 4K output (4K @ 30Hz UHD [3840×2160]) or dual HD scaler with full PiP capabilities. It can scale to two independent HDMI outputs, each with a parallel HDBaseT output. VP-778 includes both analog and embedded audio inputs and outputs and audio DSP features. It also features two microphone inputs and digital & analog balanced stereo and amplified speaker outputs. VP-778 can be controlled using built-in web pages, RS-232 and IR.

Perfect for:
Projection systems in conference rooms, boardrooms, auditoriums, hotels and churches, production studios, rental and staging
Any application where high quality switching and/or scaling of multiple and different video signals is required for projection purposes

  • Features:

    • Pix Perfectā„¢ Scaling – State-of-the-art Kramer technology.
    • K-IIT XLā„¢ Picture-in-Picture Image Insertion Technology – Ultra-stable picture-in-picture, picture-and-picture and split-screen.
    • Seamless Video Switching – Swap or follow (transition type) and cut or fade (transition effect).
    • Dual Scalers – “Live” seamless transitions with two independent outputs.
    • 8 Input Buttons per Channel.
    • Main and PiP Window Customization – In overlay mode.
    • Projection Setups – Front, back, ceiling front and ceiling back.
    • Output Resolutions – Up to 4K@30Hz UHD (3840×2160) in single-window mode, HDTV and computer graphics resolutions with selectable refresh rates.
    • Inputs – Choice of HDMI, VGA, YUV, or CV on two DVI-U inputs, 4 HDMI and 2 HDBaseT inputs.
    • Two Programmable User Buttons – For passing serial commands.
    • Serial Comms Matrix – Up to eight sets of configurable unidirectional connections for passing serial data from source to destination.
    • HDBaseTā„¢Technology – Max. data rate of 6.75Gbps (2.25Gbps per graphic channel).
    • System Range (HDBaseTā„¢) – Up to 130m (430ft) in normal mode; up to 180m (590ft) in ultra-mode (1080p @60Hz @24bpp) when using BC-UNIKAT cables.
    • Cables – For optimum range and performance, use the recommended Kramer cables available at www.kramerav.com/product/VP-778.
    • Audio – Balanced stereo audio inputs, two microphone inputs, digital stereo and balanced stereo outputs, input/output audio level adjustment, and audio DSP.
    • Built-in 2x10W Power Amplifier – Speaker outputs on a 4-pin terminal block connector.
    • Microphone – Talkover or mix modes.
    • Auto Switching – Automatically scans inputs based on a predefined priority and selects first live input found or last connected.
    • Audio-Follow-Video (AFV) & Breakaway.
    • Advanced De-interlacing – 3D comb filtering, film mode, diagonal correction, and motion detection.
    • Multiple Aspect Ratio Selections.
    • Built-in Proc-Amp – With enhanced functions such as color correction, gamma, dither, and noise reduction.
    • Power Management Modes – Save energy and money.
    • HDCP Compliance.
    • Luma – and Chroma-Keying.
    • Advanced EDID Management – Native resolution and color depth modeline per input.
    • Built-in Test Patterns – For screen setup and alignment.
    • Output EDID Analysis – For optimal scaling.
    • Input & Output Color Space Control.
    • HDMI Deep Color.
    • On-Screen Display (OSD) – Provides easy setup and adjustment.
    • Non-Volatile Memory – Retains settings.
    • Firmware Upgrade Input – Via USB memory stick.
    • Various Control Options – Front panel buttons, Ethernet web page, RS-485, IR, RS-232 serial commands transmitted by a touch screen system, PC, or other serial controller.
SKU: VP-778/110V Category: Tag:

  • Specifications:

    • INPUTS
    • 4 HDMI (deep color) connectors
    • 2 DVI-U (deep color) connectors (DVI, HDMI, PC, YPb Pr, CV)
    • 2 HDBT on RJ-45 connectors
    • 4 HDMI, 2 DVI-U, 2 HDBT on 3.5mm mini jack connectors
    • 2 Mic unbalanced and high impedance on 6mm jack connectors (with selectable 48V phantom power)
    • OUTPUTS
    • 2 HDMI (deep color) connectors
    • 2 HDBaseT on an RJ-45 connector
    • 1 S/PDIF digital audio on an RCA connector
    • 1 balanced stereo audio on a 5-pin terminal block connector
    • 1 stereo speaker output, 2x10W into 8Ī©, on a 4-pin terminal block connector
    • COMPLIANCE WITH HDMI STANDARD
    • Supports HDMI and HDCP
    • OUTPUT RESOLUTIONS
    • 640×480@60Hz, 640×480@75Hz, 800×600@50Hz, 800×600@60Hz, 800×600@75Hz, 1024×768@50Hz, 1024×768@60Hz, 1024×768@75Hz, 1280×768@50Hz, 1280×768@60Hz, 1280×800@60Hz, 1280×1024@50Hz, 1280×1024@60Hz, 1280×1024@75Hz, 1360×768@60Hz, 1366×768@50Hz, 1366×768@60Hz, 1400×1050@50Hz, 1400×1050@60Hz, 1600×900@60Hz, 1600×1200@50Hz, 1600×1200@60Hz, 1680×1050@60Hz, 1920×1200@60Hz, 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50Hz, [email protected], 720p@60Hz, [email protected], 1080p@24Hz, 1080p@25Hz, [email protected], 1080p@30HZ, 1080p@50Hz, [email protected], 1080p@60Hz, 2048×1080@60Hz, 2048×1080@50Hz, 4K2K@30Hz
    • CONTROLS
    • Front panel buttons, OSD, IR remote control, web pages, 2 RS-232 on terminal block connector, Ethernet, cond/dyn selector switch
    • OPERATING TEMPERATURE
    • 0Ā° to +40Ā°C (32Ā° to 104Ā°F)
    • STORAGE TEMPERATURE
    • -40Ā° to +70Ā°C (-40Ā° to 158Ā°F)
    • HUMIDITY
    • 10% to 90%, RHL non-condensing
    • POWER CONSUMPTION
    • 100-240V AC, 50VA max

  • Item Includes:

    • VP-778 Presentation Matrix Switcher/Dual Scaler
    • Rack ears (1 set)
    • Rubber feet (4)
    • IR remote control transmitter with batteries
    • Power cord
    • Quick start guide
    • DVI (M) to 15-pin HD (F) (AD-DM/GF) (2)
    • DVI-A (M) to 5 BNC (F) adapter cables (ADC-DMA/5BF-1) (2)
