Liberty AV BYOD-HUB-UT Connection Hub – 6 Input to HDMI Under-Table Auto Switcher

Add to Wishlist
Top BYOD-HUB-UT Specifications
  • Video Input
  • Connector Types: (1) Lighting / (1) USB Type-C / (1) Mini DP / (1) DP / (1) HDMI Type-A / (1) HDMI Type-D
  • Lighting Video Resolution: Up to 1080P@60Hz
  • USB-C Video Resolution: Up to 4Kx2K@30Hz

د.إ5,099.00

Add to Wishlist

Description

Liberty AV Solution presents the DigitaLinx BYOD-HUB-UT. This multi-format video converter connects mobile devices using the following inputs: DP, MiniDP, USB-C, Apple Lightning, HDMI, mini HDMI.

Features and Benefits

  • All listed input types converted to HDMI and scaled to 1080P or 4K
  • Cables are 4 1/2′ for under-table mounting, pass-through cubbies, table grommets, etc.
  • Output resolution can be set to 4k or 1080p
  • Auto-switching to last connected device
  • HDCP-Compliant

Applications

  • Under-table mount on conference room and huddle room tables
  • Lectern mount for BYOD connectivity in Education or Training rooms
  • Use without table mount and sit on top of table for BYOD connectivity
  • Mount on mobile carts for easy device connectivity
SKU: BYOD-HUB-UT Category: Tag:

Specifications

  • Display Port Video Resolution: Up to 4Kx2K@30Hz
  • Mini Display Port Video Resolution: Up to 4Kx2K@30Hz
  • HDMI Standard: HDMI 1.4
  • HDCP Compliance: HDCP 2.2
  • Video Bandwidth: 10.2 Gbps
  • Video Output
  • Connector Type: HDMI Type A
  • HDMI Standard: HDMI 1.4
  • HDCP Compliance: HDCP 1.4
  • Video Resolution: 4Kx2K@30Hz 4:4:4
  • General
  • Operating Temperature: 0 to +40 C (+32 to +104 F)
  • Storage Temperature: -10 to +55 C (+14 to +131 F)
  • Operating Humidity (Environment): 10% to 90%, Non-condensing
  • Dimensions (W*H*D): 5.3″ x 5.3″ x 1.2″
  • Cable Lead Length: 4.2 ft
  • Net Weight: 1.7lbs
  • Power
  • Maximum Power Consumption: 18 watts (full load, all inputs in use)
  • Power Supply Input Voltage: 100-240V AC at 50-60 Hz
  • Power Supply Output Voltage: 24V DC 1.25A
  • Regulatory: CE, FCC, RoHS
  • Other
  • Included Items: BYOD-HUB-UT Auto Switcher
  • Install Guide
  • (1) 24VDC Power Supply with 4 power plug adapters for US, EU, AU, and UK
  • (1) Mounting Bracket
  • (1) USB A to Micro USB cable
