SCLASS™ Unified Power Systems are engineered to house FlexPower® power modules alongside SWH iSTAR™ access hardware in one compact listed enclosure.
This unit is a 400W 12V and 24V DC dual voltage access power system. Two D8 modules provide sixteen auxiliary outputs and each output is configurable for 12 or 24VDC operation.
SCLASS enclosures are painted steel with removable backplate and include lock, two (2) keys and tamper switch.
Compatibility
- Fire Alarm
- Intrusion
- Access Control
- CCTV
- Mass Notification
| Category | Details |
|---|---|
| General Information | |
| Product Name | FPO150/250-2D8E8S |
| Product Line | FlexPower |
| Product Model | FPO150/250-2D8E8S |
| Product Type | Power Supply |
| Technical Information | |
| Efficiency | 87% |
| Modular | Yes |
| Power Description | |
| Input Voltage | 120 V AC, 230 V AC |
| Output Voltage | 12 V DC, 24 V DC |
| Output Voltage Detail | 12 V DC @ 12 A, 24 V DC @ 6 A 12 V DC @ 20 A, 24 V DC @ 10 A |
| Output Current | 12 A, 6 A, 20 A, 10 A |
| Output Power | 400 W |
| Physical Characteristics | |
| Form Factor | Enclosure |
| Height | 36″ |
| Width | 30″ |
| Depth | 4.5″ |
| Miscellaneous | |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Other Information | |
| Product Family | FlexPower |
