Luminex Network – LU 01 00036-POE – GigaCore 12POE Rackmount Touring 12-Port EtherCON POE Gigabit Ethernet Switch Dante Switch AES67 Switch
AED16,199.00
- Specifications:
- Most suitable applications: Touring and live events
- RLinkX (Link redundancy): Yes
- Groups (VLAN segmentation): Yes
- MultiLinkX (Link aggregation): Yes
- Profile manager: Yes
- Memory: 4Mb
- MAC adress table: 8192 Entries
- Address learning / Aging: Self learning, Auto aging
- Switching throughput: 32Gbps
- IGMP support: Yes (V1/V2/V3)
- IGMP snooping: Yes, enabled by default
- Port sensing: Auto negotiation
- Auto crossover: MDI / MDIX
- Auto sensing: Full or Half Duplex (Gigabit is Full Duplex)
- Ethernet connectivity: 12 x Shielded Neutrik Ethercon connectors
- Fiber connectivity: None
- Ethernet port speed: 1Gbps
- Serial: None
- Power connectivity: 1 x IEC inlet with fuse holder
- Power input: 100-240VAC, 50-60Hz
- Power consumption: Maximum 30W (maximum 180W with PoE Supply Unit)
- Fuse: 3.15A 250V Slow Blow
-
- Backup power input: None
- Backup PoE power input: None
- PoE supply on front ports: up to 160W
- Sound protocol compliance: Yes (low jitter)
- Ethernet compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3x Flow Control, IEEE 802.3ab Gigabit Ethernet
- Display and jog: None
- Configuration: Through the built-in web server
- Status LEDs:
- Global status LEDs: Device, power, PoE power, RLinkX
- Port status LEDs: PoE, RLinkX, link/activity and port speed
- Colored RGB LEDs: No
- Mounting: Rack
- Enclosure: Robust metal housing
- Dimensions (W x D x H): 482 x 204, 3 x 44 mm (19″ x 8.04″ x 1.73″)
- Weight: 2.8 kg
- Packaging: 545 x 335 x 80 mm (21.5″ x 13.2″ x 3.15″)
- Environment:
- Operating temperature: 0 to +50 ° C
- Storage temperature: -10 to +70 ° C
- Humidity (non condensing): 5 to 95% RH
- Certificates/Approvals: CE
- Standards: EN 60950-1, EN 55022, EN 55024
