Name: Marshall Electronics USB to RS-485/RS-422 Converter
SKU: CV-USB-RS485
Price: 199.00 AED
Availability: InStock

Marshall Electronics CV-USB-RS485 Overview

The CV-USB-RS485 is a USB to RS-485/RS-422 converter for select cameras from Marshall Electronics.

Compatible with CV502, CV505, CV565, CV343, CV345, CV365, CV350, and CV225 cameras

USB Type-A for data output and terminal pin assignment

5 x DB9 male connectors

SKU: CV-USB-RS485 Category: Controller Cards

Marshall Electronics CV-USB-RS485 Specs

Compatible Cameras	Marshall Electronics CV502, CV505, CV565, CV343, CV345, CV365, CV350, and CV225 cameras
USB Type	USB Type-A for data output and terminal pin assignment
Connectors	5 x DB9 male
Output Signal	DB9 Connector 1: T/R+ DB9 Connector 2: T/R- DB9 Connector 3: RXD+ DB9 Connector 4: RXD- DB9 Connector 5: Ground
RS-422	RS-422 full-duplex DB9 Connector 1: Send(A+) DB9 Connector 2: Send(B-) DB9 Connector 3: Receive(A+) DB9 Connector 4: Receive(B-) DB9 Connector 5: Ground Wire
RS-485	RS-485 half-duplex DB9 Connector 1: RS-485(A+) DB9 Connector 2: RS-485(B-) DB9 Connector 3: Empty DB9 Connector 4: Empty DB9 Connector 5: Ground Wire
Dimensions	Not specified by manufacturer

Packaging Info

Package Weight	0.1 lb
Box Dimensions (LxWxH)	4.2 x 4 x 1.5″
