Matrix Switch MSC-FC8BW-8 8-Channel 12G-SDI BNC to CWDM Fiber Converter

Add to Wishlist
Key Features
  • 8 x 12G-SDI BNC Inputs
  • 1 x 8-Channel CWDM Fiber Output
  • Supports SD, HD & 2K Signals
  • 8 x Installed CWDM Transmitter Modules
  • Auto Bypass of Non-Standard SDI Rates
  • Passes Embedded Audio & Ancillary Data
  • Up to 12 Mile Range
  • Passes Embedded Audio & Ancillary Data

AED35,699.00

Add to Wishlist

The MSC-FC8BW-8 8-Channel 12G-SDI to Fiber Converter from Matrix Switch can be used to transmit up to eight channels of SDI signals via a single CWDM LC fiber cable at distances up to 12 miles. This converter incorporates eight factory installed LC CWDM fiber transmitter modules and includes an external power supply.

CWDM Transmitters
The MSC-FC8BW-8 converter includes eight MSC-SFPTX-W factory installed CWDM transmitter modules.
Long Range
Transmits using a single fiber cable at distances up to 12 miles.
Pass Through
This converter passes SDI embedded audio and ancillary data.
SKU: MSC-FC8BW-8 Category: Tag:
Inputs / Outputs
Video Inputs
8x BNC (3G-SDI) Female
Audio Inputs
No
Video Outputs
1x LC Fiber (CWDM) Female
Audio Outputs
No
Expansion Slots
No
Format Support
Input Video Format
SDI (10-Bit 4:4:4/4:2:2 RGB, YUV)
2048 x 1556 at 23.98/24/25 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
576i / 625 lines at 25 fps
480i / 525 lines at 29.97 fps
Embedded Audio
SDI Input
Fiber Output
Standards
Video Standard Compliance
SMPTE 259M/292M/296M/310M/425M-A/425M-B/297-2006
ITU -R BT.601/BT.656
HDR Support
Not Specified by Manufacturer
Environmental
Operating Temperature
32 to 102°F / 0 to 70°C
Storage Temperature
14 to 194°F / -10 to 90°C
General
Certifications
FCC, UL, CE, RoHS
Dimensions
13 x 6 x 2.5″ / 33 x 15.2 x 6.3 cm
Weight
5 lb / 2.3 kg
