Power Supply
MSI Meg AI1600T PCIE5 Power Supply Unit
- Supports Nvidia® GeForce RTXTM 50 Series graphics cards
- Dual-native 12V-2×6 Connectors
- Server-grade materials, SiC interleaved PFC MOSFET
- Tri-certified Titanium certification (80 PLUS / Cybenetics / PPLP)
- PCIe 5.1 and ATX 3.1 Ready
- Dual-color 12V-2×6 cables
- 100% all Japanese 105oC capacitor
- Full digital design with control MCU
- Industrial level protection with OCP/ OTP/ OPP/ SCP/ OVP/ UVP/ SIP/ NLO
AED4,699.00
MSI’s flagship MEG series exemplifies relentless innovation, continuously setting new benchmarks in the gaming hardware space. This trailblazing series employs pioneering technology to push the boundaries of gaming, consistently leading with innovations that redefine what gamers expect.
PERFORMANCE | THERMAL DESIGN | DURABILITY | EZ DIY | GAMING INTELLIGENCE | Quality Test Challenges
Each product undergoes hundreds of strict quality checks before leaving the factory to ensure it reaches consumers with assured quality. The MEG Ai1600T PCIE5 reveals the most important items result, users can witness each test, showcasing its quality.
| Category | Attribute | Details |
|---|---|---|
| General Information | Product Name | Meg AI1600T PCIE5 Power Supply Unit |
| Manufacturer Part Number | MEGAI1600TPCIE5 | |
| Product Series | MEG | |
| Product Type | Power Supply | |
| Technical Information | Specification Compliance | ATX 3.1 |
| Efficiency | 94% | |
| Power Factor Correction (PFC) | Active | |
| Number of Fans | 1 | |
| Fan Bearing Type | Dual Ball Fan Bearing | |
| Fan Diameter | 135 mm | |
| Protection Type | Over Current, Over Temperature, Over Power, Short Circuit, Over Voltage, Under Voltage, Surge & Inrush Protection, No Load |
|
| Modular | Yes | |
| NVIDIA SLI Supported | Yes | |
| Interfaces/Ports | Number of SATA Power Connectors | 8 |
| PCI Express Connector | Yes | |
| Number of (6+2 pin) PCI Express Power Connectors | 9 | |
| Number of (4+4 pin) CPU Power Connectors | 2 | |
| Number of 4-pin Molex Power Connectors | 8 | |
| Power Description | Input Voltage | 120 V AC, 230 V AC |
| Input Frequency | 60 Hz | |
| Number of +12V Rails | 1 | |
| Output Voltage | 5 V DC, 3.3 V DC, 12 V DC, -12 V DC, 5 V SB | |
| Output Voltage Detail | 5 V DC @ 22 A 3.3 V DC @ 22 A 12 V DC @ 133.3 A -12 V DC @ 0.3 A 5 V SB @ 3 A |
|
| Output Power | 1600 W | |
| Physical Characteristics | Form Factor | Internal |
| Height | 7.5″ | |
| Width | 5.9″ | |
| Depth | 3.4″ | |
| Miscellaneous | Energy Efficiency Certification | 80 Plus Titanium |
| Other Information | Product Family | MEG |
