Switch type |
Unmanaged |
Basic switching RJ-45 Ethernet ports quantity |
10 |
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity |
8 |
Power connector |
DC-in jack |
Networking standards |
IEEE 802.1p, IEEE 802.3az, IEEE 802.3x |
10G support |
Y |
Cable types supported |
Cat5, Cat5e, Cat6, Cat6a, Cat7 |
Full duplex |
Y |
Flow control support |
Y |
VLAN support |
N |
MAC address table |
16000 entries |
Switching capacity |
56 Gbit/s |
Forwarding rate |
41.664 Mpps |
Latency (10-100 Mbps) |
7 µs |
Latency (1 Gbps) |
4 µs |
Latency (10 Gbps) |
3 µs |
Number of queues |
8 |
Jumbo frames support |
Y |
Jumbo frames |
10240 |
Packet buffer memory |
0.128 MB |
Queue scheduling algorithms |
Weighted Round Robin (WRR) |
Rack mounting |
Y |
Product colour |
Black |
Housing material |
Metal |
LED indicators |
Link, Power, Speed |
Wall mountable |
Y |
Safety |
UL/cUL Listed (UL 60950-1)/CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015 |
Electromagnetic compatibility |
Class B |
Certification |
47 CFR FCC Part 15, SubpartB, Class B ICES-003:2016 Issue 6, Class B ANSI C63.4:2014 N 55032:2012 +AC:2013 / CISPR 32:2012 / AS/NZS CISPR 32:2013, Class B EN 55032:2015 +AC:2016 / CISPR 32:2015 +COR1:2016 / AS/NZS CISPR 32:2015, Class B EN 61000-3-2:2014 EN 61000-3-3:2013 EN 55024:2010 +A1:2015 |
Shipping (inner) case height |
33.9 cm |
Shipping (inner) case width |
49 cm |
Shipping (inner) case length |
39.1 cm |
Shipping (inner) case net weight |
14.5 kg |
Products per shipping (inner) case |
10 pc(s) |
Master (outer) cases per pallet layer |
6 pc(s) |
Layers per pallet (air) |
4 pc(s) |
Layers per pallet (sea) |
6 pc(s) |
Output voltage |
12 V |
Output current |
1.5 A |
Power consumption (typical) |
4.8 W |
Power consumption (max) |
13.2 W |
Power over Ethernet (PoE) |
N |
Operating temperature (T-T) |
0 – 40 °C |
Storage temperature (T-T) |
-20 – 70 °C |
Operating relative humidity (H-H) |
0 – 90% |
Storage relative humidity (H-H) |
0 – 95% |
Operating altitude |
0 – 3000 m |
Non-operating altitude |
0 – 3000 m |
Heat dissipation |
45.14 BTU/h |
Width |
236 mm |
Depth |
102 mm |
Height |
27 mm |
Weight |
740 g |
Quick start guide |
Y |
Wall mounting kit |
Y |
AC adapter included |
Y |
Rack mount kit |
Y |
Rubber feet |
Y |
Package width |
164 mm |
Package depth |
270 mm |
Package height |
85 mm |
Package weight |
1.25 kg |
